P25E-100S-EA
Active3M
CONN IDC CONNECTOR F 100 POS 1.27MM IDT RA SIDE ENTRY CABLE MOUNT BOX
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | P25E-100S-EA | P25E Series |
|---|---|---|
| Cable Termination | IDC | IDC |
| Color | Black | Black |
| Connector Type | Receptacle | Receptacle |
| Contact Finish | Gold | Gold |
| Contact Finish Thickness | Flash | Flash |
| Contact Finish Thickness | - | 10 Áin |
| Contact Finish Thickness | - | 0.25 Ám |
| Contact Type | Female Socket | Female Socket |
| Fastening Type | Latch Lock/Eject Hooks | Latch Lock/Eject Hooks |
| Features | Feed Through | Feed Through |
| Mounting Type | Free Hanging (In-Line) | Free Hanging (In-Line) |
| Number of Positions | 100 | 20 - 100 |
| Number of Rows | 2 | 2 |
| Pitch [x] | 0.05 in | 0.05 in |
| Pitch [x] | 1.27 mm | 1.27 mm |
| Wire Gauge | 30 AWG | 30 AWG |
| Wire Type | Ribbon Cable | Ribbon Cable |
P25E Series
CONN RCPT 100POS IDC 30AWG GOLD
| Part | Contact Type | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Wire Type | Contact Finish | Color | Cable Termination | Pitch [x] | Pitch [x] | Wire Gauge | Fastening Type | Connector Type | Features | Number of Rows | Mounting Type | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Female Socket | 100 | 10 Áin | 0.25 Ám | Ribbon Cable | Gold | Black | IDC | 0.05 in | 1.27 mm | 30 AWG | Latch Lock/Eject Hooks | Receptacle | Feed Through | 2 | Free Hanging (In-Line) | ||
Female Socket | 50 | 10 Áin | 0.25 Ám | Ribbon Cable | Gold | Black | IDC | 0.05 in | 1.27 mm | 30 AWG | Latch Lock/Eject Hooks | Receptacle | Feed Through | 2 | Free Hanging (In-Line) | ||
Female Socket | 40 | Ribbon Cable | Gold | Black | IDC | 0.05 in | 1.27 mm | 30 AWG | Latch Lock/Eject Hooks | Receptacle | Feed Through | 2 | Free Hanging (In-Line) | Flash | |||
Female Socket | 100 | Ribbon Cable | Gold | Black | IDC | 0.05 in | 1.27 mm | 30 AWG | Latch Lock/Eject Hooks | Receptacle | Feed Through | 2 | Free Hanging (In-Line) | Flash | |||
Female Socket | 20 | Ribbon Cable | Gold | Black | IDC | 0.05 in | 1.27 mm | 30 AWG | Latch Lock/Eject Hooks | Receptacle | Feed Through | 2 | Free Hanging (In-Line) | Flash | |||
Female Socket | 50 | Ribbon Cable | Gold | Black | IDC | 0.05 in | 1.27 mm | 30 AWG | Latch Lock/Eject Hooks | Receptacle | Feed Through | 2 | Free Hanging (In-Line) | Flash | |||
Female Socket | 60 | Ribbon Cable | Gold | Black | IDC | 0.05 in | 1.27 mm | 30 AWG | Latch Lock/Eject Hooks | Receptacle | Feed Through | 2 | Free Hanging (In-Line) | Flash |
