159-2801-034

Unknown

Amphenol Spectra-Strip

CBL RIBN 34COND 0.05 BLACK 10'

Search across all available documentation for this part.

Unknown

Amphenol Spectra-Strip

CBL RIBN 34COND 0.05 BLACK 10'

Technical Specifications

Parameters and characteristics for this part

CBL RIBN 34COND 0.05 BLACK 10'

Part	Shielding	Number of Conductors	Voltage	Length [x]	Length [x]	Ribbon Thickness	Ribbon Thickness	Conductor Material	Wire Gauge	Pitch [x]	Pitch [x]	Current Rating (Amps)	Ribbon Width [y]	Ribbon Width [y]	Insulation Resistance	Operating Temperature [Min]	Operating Temperature [Max]	Jacket Color	First Conductor Mark	Jacket (Insulation) Material	Conductor Strand [custom]	Conductor Strand [custom]	Cable Type
Amphenol Spectra-Strip 159-2801-034	Shielded	34	300 V	3.05 m	10 ft	0.89 mm	0.035 in	Copper, Tinned	28 AWG	0.05 in	1.27 mm	1.3 A	1.7 in	43.18 mm	10 GOhm	-40 °C	105 ░C	Black	Red	Poly-Vinyl Chloride (PVC)	7	36 AWG	Flat Cable, Round Jacket

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Flat Ribbon Cable Black 34 Conductors 0.050" (1.27mm) Flat Cable, Round Jacket 10.0' (3.05m)

Technical documentation and resources
