MAX12005EVKIT#

Active

Analog Devices Inc./Maxim Integrated

EVAL KIT MAX12005 (SATELLITE IF

Search across all available documentation for this part.

Active

Analog Devices Inc./Maxim Integrated

EVAL KIT MAX12005 (SATELLITE IF

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	MAX12005EVKIT#	MAX12005 Series

For Use With/Related Products	MAX12005	MAX12005
Frequency [Max]	3 GHz	3 GHz
Frequency [Min]	100 kHz	100 kHz
Frequency Range	-	950 MHz
Frequency Range	-	2.15 GHz
Impedance	-	75 Ohms
Isolation	-	55 dB
Mounting Type	-	Surface Mount
Operating Temperature	-	85 °C
Operating Temperature	-	-40 °C
Package / Case	-	48-WFQFN Exposed Pad
RF Type	-	DBS, L-Band, IF Satellite
Supplied Contents	Board(s)	Board(s)
Supplier Device Package	-	48-TQFN (7x7)
Test Frequency	-	950 MHz
Topology	-	Reflective
Type	Switch	Switch
Voltage - Supply	-	3 V
Voltage - Supply	-	3.5 V

IC RF SWITCH 2.15GHZ 48TQFN

Part	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Topology	Mounting Type	Isolation	Voltage - Supply [Min]	Voltage - Supply [Max]	Impedance	RF Type	Supplier Device Package	Frequency Range [Min]	Frequency Range [Max]	Test Frequency	Frequency [Min]	Frequency [Max]	Type	For Use With/Related Products	Supplied Contents
Analog Devices Inc./Maxim Integrated MAX12005ETM+	85 °C	-40 °C	48-WFQFN Exposed Pad	Reflective	Surface Mount	55 dB	3 V	3.5 V	75 Ohms	DBS, IF Satellite, L-Band	48-TQFN (7x7)	950 MHz	2.15 GHz	950 MHz
Analog Devices Inc./Maxim Integrated MAX12005EVKIT#															100 kHz	3 GHz	Switch	MAX12005	Board(s)
Analog Devices Inc./Maxim Integrated MAX12005ETM+T	85 °C	-40 °C	48-WFQFN Exposed Pad	Reflective	Surface Mount	55 dB	3 V	3.5 V	75 Ohms	DBS, IF Satellite, L-Band	48-TQFN (7x7)	950 MHz	2.15 GHz	950 MHz

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 446.59

General part information

- MAX12005 Switch 100kHz ~ 3GHz Evaluation Board
