KHNA90F-24-E

Active

Cosel USA, Inc.

AC/DC DIN RAIL SUPPLY 24V 90W

Search across all available documentation for this part.

Active

Cosel USA, Inc.

AC/DC DIN RAIL SUPPLY 24V 90W

Technical Specifications

Parameters and characteristics for this part

Specification	KHNA90F-24-E

AC Voltage - Input [Max]	264 VAC
AC Voltage - Input [Min]	85 VAC
Applications	ITE (Commercial)
Approval Agency	TUV, CE, cULus, cURus
Current - Output (Max) [Max]	3.8 A
DC Voltage - Input (Max) [Max]	370 V
DC Voltage - Input (Min) [Min]	120 V
Efficiency	91 %
Features	PFC, Remote On/Off, Universal Input, Adjustable Output
Input Type	AC or DC
Number of Outputs	1
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-20 C
Power (Watts)	90 W
Size / Dimension [x]	121.2 mm
Size / Dimension [x]	4.77 in
Size / Dimension [y]	1.97 "
Size / Dimension [y]	50 mm
Size / Dimension [z]	4.88 "
Size / Dimension [z]	124 mm
Standard Number	60950-1
Voltage - Isolation	3000 V
Voltage - Output 1	24 V

Part	Operating Temperature [Min]	Operating Temperature [Max]	Efficiency	Voltage - Isolation	Number of Outputs	Applications	Power (Watts)	Current - Output (Max) [Max]	Features	Voltage - Output 1	Standard Number	Input Type	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Approval Agency	DC Voltage - Input (Min) [Min]	AC Voltage - Input [Min]	AC Voltage - Input [Max]	DC Voltage - Input (Max) [Max]
Cosel USA, Inc. KHNA90F-12	-20 C	70 °C	88 %	3000 V	1	ITE (Commercial)	90 W	6.8 A	Adjustable Output PFC Remote On/Off Universal Input	12 V	60950-1	AC or DC	121.2 mm	4.77 in	4.88 "	124 mm	1.97 "	50 mm	CE cULus cURus TUV	120 V	85 VAC	264 VAC	370 V
Cosel USA, Inc. KHNA90F-24	-20 C	70 °C	91 %	3000 V	1	ITE (Commercial)	90 W	3.8 A	Adjustable Output PFC Remote On/Off Universal Input	24 V	60950-1	AC or DC	121.2 mm	4.77 in	4.88 "	124 mm	1.97 "	50 mm	CE cULus cURus TUV	120 V	85 VAC	264 VAC	370 V
Cosel USA, Inc. KHNA90F-24-E	-20 C	70 °C	91 %	3000 V	1	ITE (Commercial)	90 W	3.8 A	Adjustable Output PFC Remote On/Off Universal Input	24 V	60950-1	AC or DC	121.2 mm	4.77 in	4.88 "	124 mm	1.97 "	50 mm	CE cULus cURus TUV	120 V	85 VAC	264 VAC	370 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

AC/DC DIN RAIL SUPPLY 24V 90W
