MPM-20-3.3

Active

MEAN WELL USA Inc.

AC/DC CONVERTER 3.3V 15W

Search across all available documentation for this part.

Active

MEAN WELL USA Inc.

AC/DC CONVERTER 3.3V 15W

Technical Specifications

Parameters and characteristics for this part

Specification	MPM-20-3.3

Applications	Household Appliances, Medical
Approval Agency	TUV, cURus, EAC, CE, CB
Current - Output (Max) [Max]	4.5 A
Efficiency	81 %
Features	Universal Input
Line Regulation	0.5 %
Load Regulation	0.5 %
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-35 °C
Package / Case	4-DIP Module
Power (Watts)	15 W
Size / Dimension [x]	2.06 in
Size / Dimension [x]	52.3 mm
Size / Dimension [y]	27.2 mm
Size / Dimension [y]	1.07 in
Size / Dimension [z]	23.8 mm
Size / Dimension [z]	0.94 in
Type	Enclosed
Voltage - Input [Max]	264 VAC
Voltage - Input [Min]	80 VAC
Voltage - Output 1	3.3 V

Part	Voltage - Input [Max]	Voltage - Input [Min]	Number of Outputs	Package / Case	Mounting Type	Features	Power (Watts)	Load Regulation	Line Regulation	Efficiency	Approval Agency	Type	Voltage - Output 1	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Current - Output (Max) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Applications
MEAN WELL USA Inc. MPM-20-3.3	264 VAC	80 VAC	1	4-DIP Module	Through Hole	Universal Input	15 W	0.5 %	0.5 %	81 %	CB CE cURus EAC TUV	Enclosed	3.3 V	27.2 mm	1.07 in	2.06 in	23.8 mm	52.3 mm	0.94 in	4.5 A	-35 °C	85 °C	Household Appliances Medical

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Enclosed AC DC Converters 1 Output 3.3V 4.5A 80 ~ 264 VAC Input
