860-R03-213R004

Active

MH Connectors

CONN PLUG FMALE 3POS GOLD SOLDER

Search across all available documentation for this part.

Active

MH Connectors

CONN PLUG FMALE 3POS GOLD SOLDER

Technical Specifications

Parameters and characteristics for this part

Specification	860-R03-213R004

Color	Silver
Connector Type	Female Sockets, Plug
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	10 çin
Contact Finish Thickness - Mating	0.25 çm
Contact Material	Brass
Current Rating (Amps)	4 A
Ingress Protection	IP67 - Dust Tight, Waterproof
Insert Material	Polybutylene Terephthalate (PBT)
Material Flammability Rating	UL94 V-0
Mounting Feature	Bulkhead - Front Side Nut
Mounting Type	Through Hole, Panel Mount
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Orientation	A
Primary Material	Metal
Shell Finish	Nickel
Shell Material	Brass
Shell Size - Insert	M12-3
Shielding	Shielded
Termination	Solder
Voltage Rating	250 VDC

Part	Shell Material	Mounting Type	Shell Finish	Shielding	Shell Size - Insert	Current Rating (Amps)	Contact Material	Termination	Insert Material	Mounting Feature	Ingress Protection	Orientation	Color	Contact Finish - Mating	Connector Type	Material Flammability Rating	Voltage Rating	Primary Material	Operating Temperature [Max]	Operating Temperature [Min]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating
MH Connectors 860-R03-213R004	Brass	Panel Mount Through Hole	Nickel	Shielded	M12-3	4 A	Brass	Solder	Polybutylene Terephthalate (PBT)	Bulkhead - Front Side Nut	IP67 - Dust Tight Waterproof	A	Silver	Gold	Female Sockets Plug	UL94 V-0	250 VDC	Metal	85 °C	-40 °C	10 çin	0.25 çm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	50	$ 13.14

General part information

3 Position Circular Connector Plug, Female Sockets Solder
