NM-24-R24

Active

Essentra Access Solutions

FASTENER, SCREW MOUNT CABLE CLAMP, 1.5 ", NYLON (POLYAMIDE), GREEN, 0.553 "

Search across all available documentation for this part.

Active

Essentra Access Solutions

FASTENER, SCREW MOUNT CABLE CLAMP, 1.5 ", NYLON (POLYAMIDE), GREEN, 0.553 "

Technical Specifications

Parameters and characteristics for this part

Specification	NM-24-R24

Bundle Center to Mounting Center [x]	1.17 in
Bundle Center to Mounting Center [x]	29.72 mm
Color	Green
Features	Eyelet, Heat Stabilized
Material	Polyamide (PA66), Nylon 6/6
Material Flammability Rating	UL94 V-2
Material Thickness	3.05 mm
Material Thickness	0.12 in
Mounting Type	Fastener
Opening Size [diameter]	1.5 in
Opening Size [diameter]	38.1 mm
Panel Hole Size [diameter]	5.23 mm
Panel Hole Size [diameter]	0.206 in
Screw Size	M5
Screw Size	#10
Type	Clamp, P-Type
Type Attributes	Ribbed
Width [x]	14.05 mm
Width [x]	0.553 in

Part	Material	Opening Size [diameter]	Opening Size [diameter]	Color	Bundle Center to Mounting Center [x]	Bundle Center to Mounting Center [x]	Type Attributes	Material Thickness	Material Thickness	Mounting Type	Width [x]	Width [x]	Type	Panel Hole Size [diameter]	Panel Hole Size [diameter]	Screw Size	Screw Size	Material Flammability Rating	Features
Essentra Access Solutions NM-24-R24	Polyamide (PA66) Nylon 6/6	1.5 in	38.1 mm	Green	1.17 in	29.72 mm	Ribbed	3.05 mm	0.12 in	Fastener	14.05 mm	0.553 in	Clamp P-Type	5.23 mm	0.206 in	M5	#10	UL94 V-2	Eyelet Heat Stabilized

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Cable Clamp, P-Type Green Fastener 1.500" (38.10mm)
