SF1122-6033

Active

Amphenol SV Microwave

CONN ADAPT SMA JACK-ZMA PLUG

Search across all available documentation for this part.

Active

Amphenol SV Microwave

CONN ADAPT SMA JACK-ZMA PLUG

Technical Specifications

Parameters and characteristics for this part

Specification	SF1122-6033

Adapter Series	SMA to ZMA
Adapter Type	Plug to Jack
Body Material	Stainless Steel
Center Contact Material	Beryllium Copper
Center Contact Plating	Gold
Conversion Type	Between Series
Convert From (Adapter End)	Female Socket, SMA Jack
Convert To (Adapter End)	ZMA Plug, Male Pin
Dielectric Material	Polytetrafluoroethylene (PTFE)
Fastening Type	Bayonet Lock, Threaded
Features	Three Lug
Frequency - Max [Max]	12.4 GHz
Impedance	50 Ohms
Mating Cycles	500
Mounting Type	Free Hanging (In-Line)
Style	Straight

Part	Dielectric Material	Conversion Type	Impedance	Body Material	Style	Frequency - Max [Max]	Features	Center Contact Plating	Adapter Type	Adapter Series	Convert From (Adapter End)	Fastening Type	Mating Cycles	Center Contact Material	Convert To (Adapter End)	Mounting Type
Amphenol SV Microwave SF1122-6033	Polytetrafluoroethylene (PTFE)	Between Series	50 Ohms	Stainless Steel	Straight	12.4 GHz	Three Lug	Gold	Plug to Jack	SMA to ZMA	Female Socket SMA Jack	Bayonet Lock Threaded	500	Beryllium Copper	Male Pin ZMA Plug	Free Hanging (In-Line)
Amphenol SV Microwave SF1122-6031	Polytetrafluoroethylene (PTFE)	Between Series	50 Ohms	Stainless Steel	Straight	12.4 GHz	Four Lug	Gold	Plug to Jack	SMA to ZMA	Female Socket SMA Jack	Bayonet Lock Threaded	500	Beryllium Copper	Male Pin ZMA Plug	Free Hanging (In-Line)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	25	$ 204.12

General part information

Adapter Coaxial Connector SMA Jack, Female Socket To ZMA Plug, Male Pin 50 Ohms
