AM3G-0505DH30Z

Active

aimtec

DC DC CONVERTER +/-5V 3W

Search across all available documentation for this part.

Active

aimtec

DC DC CONVERTER +/-5V 3W

Technical Specifications

Parameters and characteristics for this part

Part	Voltage - Input (Min) [Min]	Operating Temperature [Min]	Operating Temperature [Max]	Features	Efficiency	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Voltage - Input (Max) [Max]	Current - Output (Max) [Max]	Type	Package / Case	Mounting Type	Supplier Device Package	Voltage - Output 1	Applications	Number of Outputs	Voltage - Isolation	Voltage - Output 2	Power (Watts)	Package / Case	Approval Agency	Current - Output (Max)
aimtec AM3G-0505S-NZ	4.5 V	-40 °C	100 °C	Remote On/Off	73 %	0.47 "	22 mm	0.37 "	0.87 in	9.5 mm	12 mm	9 V	500 mA	Isolated Module	8-SIP Module	Through Hole	8-SIP	5 V	ITE (Commercial)	1	1.5 kV
aimtec AM3G-0505DH30Z	4.5 V	-40 °C	71 °C	Remote On/Off	77 %	0.44 "	21.9 mm	0.36 "	0.86 in	9.2 mm	11.2 mm	9 V		Isolated Module	8-SIP Module	Through Hole		5 V	ITE (Commercial)	2	3000 V	-5 V	3 W	7 Leads	CE cURus UL	300 mA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Isolated Module DC DC Converter 2 Output 5V -5V 300mA, 300mA 4.5V - 9V Input
