AA15S1200C

Obsolete

Delta Electronics

AC/DC CONVERTER 12V 15W

Search across all available documentation for this part.

Obsolete

Delta Electronics

AC/DC CONVERTER 12V 15W

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Enclosed AC DC Converters 1 Output 12V 85 ~ 264 VAC Input

Technical documentation and resources

Parameters and characteristics commom to parts in this series

Specification	AA15S1200C	AA15S Series

Applications	ITE (Commercial)	ITE (Commercial)
Approval Agency	CE	cUL, UL, CE
Current - Output (Max)	-	1.25 A
Current - Output 1	1.25 A	1.25 A
Efficiency	79 %	79 %
Features	Universal Input, DC Input Capable	Universal Input, DC Input Capable
Line Regulation	-	0.5 %
Load Regulation	-	0.5 %
Minimum Load Required	False	False
Mounting Type	Chassis Mount	Through Hole, Chassis Mount
Number of Outputs	1	1
Operating Temperature [Max]	70 °C	70 °C
Operating Temperature [Min]	-25 °C	-25 °C
Package / Case	-	7-DIP Module
Package / Case	-	4 Lead
Power (Watts)	15 W	15 W
Size / Dimension [x]	74 mm	74 mm
Size / Dimension [x]	2.91 "	2.91 "
Size / Dimension [y]	54 mm	54 mm
Size / Dimension [y]	2.13 in	2.13 in
Size / Dimension [z]	0.77 "	0.77 "
Size / Dimension [z]	19.5 mm	19.5 mm
Standard Number	-	60950-1
Type	Enclosed	Enclosed
Voltage - Isolation	3000 V	3000 V
Voltage - Output 1	12 V	12 - 24 V
Weight	-	161.93 g
Weight	-	0.357 lb

AC/DC CONVERTER 12V 15W

Part	Power (Watts)	Load Regulation	Efficiency	Applications	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Voltage - Output 1	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Standard Number	Line Regulation	Package / Case	Package / Case	Number of Outputs	Features	Weight	Weight	Type	Current - Output (Max) [Max]	Approval Agency	Voltage - Isolation	Current - Output 1
Delta Electronics AA15S1200A	15 W	0.5 %	79 %	ITE (Commercial)	-25 °C	70 °C	Through Hole	12 V	74 mm	2.91 "	0.77 "	19.5 mm	54 mm	2.13 in	60950-1	0.5 %	7-DIP Module	4 Lead	1	Universal Input	161.93 g	0.357 lb	Enclosed	1.25 A	CE, cUL, UL
Delta Electronics AA15S2400C	15 W		79 %	ITE (Commercial)	-25 °C	70 °C	Chassis Mount	24 V	74 mm	2.91 "	0.77 "	19.5 mm	54 mm	2.13 in					1	DC Input Capable, Universal Input			Enclosed		CE	3000 V
Delta Electronics AA15S1200C	15 W		79 %	ITE (Commercial)	-25 °C	70 °C	Chassis Mount	12 V	74 mm	2.91 "	0.77 "	19.5 mm	54 mm	2.13 in					1	DC Input Capable, Universal Input			Enclosed		CE	3000 V	1.25 A
