Part	Number of Positions	Number of Rows	Insulation Height	Features	Style	Pitch - Mating	Mounting Type	Contact Length - Mating	Contact Finish Thickness - Mating	Connector Type	Contact Shape	Number of Positions Loaded	Insulation Color	Contact Type	Material Flammability Rating	Contact Finish - Post	Fastening Type	Termination	Contact Material	Shrouding	Contact Finish - Mating	Insulation Material	Operating Temperature (Max)	Operating Temperature (Min)	Row Spacing - Mating	Number of Positions Loaded	Contact Finish Thickness - Post
Samtec Inc. TSM-104-02-L-SH-A-K-TR	4	1	0.12 in	Board Guide Pick and Place	Board Board or Cable	0.1 in	Right Angle Surface Mount	0.32 in	10 µin	Header	Square	All	Black	Male Pin	UL94 V-0	Tin	Push-Pull	Solder	Phosphor Bronze	Unshrouded	Gold	Liquid Crystal Polymer (LCP)	125 °C	-55 °C
Samtec Inc. TSM-104-02-S-SH-A-TR	4	1	0.12 in	Board Guide	Board Board or Cable	0.1 in	Right Angle Surface Mount	0.32 in	30 µin	Header	Square	All	Black	Male Pin	UL94 V-0	Tin	Push-Pull	Solder	Phosphor Bronze	Unshrouded	Gold	Liquid Crystal Polymer (LCP)	125 °C	-55 °C
Samtec Inc. TSM-104-02-T-SV-A-P	4	1	0.1 in	Board Guide Pick and Place	Board Board or Cable	0.1 in	Surface Mount	0.32 in		Cuttable Header	Square	All	Black	Male Pin	UL94 V-0	Tin	Push-Pull	Solder	Phosphor Bronze	Unshrouded	Tin	Liquid Crystal Polymer (LCP)	105 °C	-55 °C
Samtec Inc. TSM-104-02-S-SH-LC	4	1	0.12 in	Board Lock	Board Board or Cable	0.1 in	Right Angle Surface Mount	0.32 in	30 µin	Header	Square	All	Black	Male Pin	UL94 V-0	Tin	Push-Pull	Solder	Phosphor Bronze	Unshrouded	Gold	Liquid Crystal Polymer (LCP)	125 °C	-55 °C
Samtec Inc. TSM-104-03-T-SV-P-TR	4	1	0.1 in	Pick and Place	Board Board or Cable	0.1 in	Surface Mount	0.42 in		Cuttable Header	Square	All	Black	Male Pin	UL94 V-0	Tin	Push-Pull	Solder	Phosphor Bronze	Unshrouded	Tin	Liquid Crystal Polymer (LCP)	105 °C	-55 °C
Samtec Inc. TSM-104-01-F-DH-A	8	2	0.24 in	Board Guide	Board Board or Cable	0.1 in	Right Angle Surface Mount	0.23 in	3 µin	Header	Square	All	Black	Male Pin	UL94 V-0	Tin	Push-Pull	Solder	Phosphor Bronze	Unshrouded	Gold	Liquid Crystal Polymer (LCP)	125 °C	-55 °C	0.1 in
Samtec Inc. TSM-104-01-S-EM-007	8	2			Board Board or Cable	0.1 in	Board Edge Straddle Mount	0.23 in	30 µin	Header	Square		Black	Male Pin	UL94 V-0	Tin	Push-Pull	Solder	Phosphor Bronze	Unshrouded	Gold	Liquid Crystal Polymer (LCP)	125 °C	-55 °C	0.1 in	7
Samtec Inc. TSM-104-01-S-DV-006	8	2	0.1 in		Board Board or Cable	0.1 in	Surface Mount	0.23 in	30 µin	Cuttable Header	Square		Black	Male Pin	UL94 V-0	Tin	Push-Pull	Solder	Phosphor Bronze	Unshrouded	Gold	Liquid Crystal Polymer (LCP)	125 °C	-55 °C	0.1 in	7
Samtec Inc. TSM-104-04-G-SH-P-TR	4	1	0.12 in	Pick and Place	Board Board or Cable	0.1 in	Right Angle Surface Mount	0.12 in	10 µin	Header	Square	All	Black	Male Pin	UL94 V-0	Gold	Push-Pull	Solder	Phosphor Bronze	Unshrouded	Gold	Liquid Crystal Polymer (LCP)	125 °C	-55 °C			3 µin
Samtec Inc. TSM-104-04-S-DV-P-TR	8	2	0.1 in	Pick and Place	Board Board or Cable	0.1 in	Surface Mount	0.12 in	30 µin	Cuttable Header	Square	All	Black	Male Pin	UL94 V-0	Tin	Push-Pull	Solder	Phosphor Bronze	Unshrouded	Gold	Liquid Crystal Polymer (LCP)	125 °C	-55 °C	0.1 in

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

TSM-104-02-SM-SV | Datasheet
