C277LAC5300VA1J

Active

KEMET

CAP FILM 30UF 5% 425VAC RADIAL

Search across all available documentation for this part.

Active

KEMET

CAP FILM 30UF 5% 425VAC RADIAL

Technical Specifications

Parameters and characteristics for this part

Specification	C277LAC5300VA1J

Applications	Motor Run
Capacitance	30 µF
Dielectric Material	Metallized, Polypropylene (PP)
Mounting Type	Chassis, Stud Mount
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-25 °C
Package / Case	Radial, Can
Tolerance	5 %
Voltage Rating - AC	425 V

Part	Package / Case	Capacitance	Mounting Type	Applications	Dielectric Material	Voltage Rating - AC	Tolerance	Operating Temperature [Min]	Operating Temperature [Max]
KEMET C277LAC5300VA1J	Radial Can	30 µF	Chassis Stud Mount	Motor Run	Metallized Polypropylene (PP)	425 V	5 %	-25 °C	85 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	420	$ 6.51
Newark	Each	250	$ 6.27
		500	$ 5.82

General part information

30 µF Film Capacitor 425V Polypropylene (PP), Metallized Radial, Can
