42BF15AF
ActiveSiemens
CONTACTOR, 42DP,30A,2P,OPEN,120V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
42BF15AF
ActiveSiemens
CONTACTOR, 42DP,30A,2P,OPEN,120V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 42BF15AF |
|---|---|
| Coil Voltage [Max] | 120 VAC |
| Coil Voltage [Min] | 110 VAC/DC |
| Contact Form | DPST-NO (2 Form A) |
| Contact Rating (Current) | 30 A |
| Features | Auxiliary Contacts |
| Mounting Type | Chassis Mount |
| Operating Temperature | 70 °C |
| Switching Voltage | 600 VAC |
| Termination Style | Screw Terminal |
42BF Series
| Part | Mounting Type | Operating Temperature | Termination Style | Features | Coil Voltage [Max] | Coil Voltage [Min] | Contact Rating (Current) | Switching Voltage | Contact Form | Coil Voltage |
|---|---|---|---|---|---|---|---|---|---|---|
Siemens | Chassis Mount | 70 °C | Screw Terminal | Auxiliary Contacts | 480 VAC/DC | 440 VAC/DC | 30 A | 600 VAC | 3PST-NO (3 Form A) | |
Siemens | Chassis Mount | 70 °C | Screw Terminal | Auxiliary Contacts | 30 A | 600 VAC | 3PST-NO (3 Form A) | 24 VAC | ||
Siemens | Chassis Mount | 70 °C | Screw Terminal | Auxiliary Contacts | 120 VAC | 110 VAC/DC | 30 A | 600 VAC | DPST-NO (2 Form A) | |
Siemens | Chassis Mount | 70 °C | Screw Terminal | Auxiliary Contacts | 240 VAC | 208 VAC | 30 A | 600 VAC | DPST-NO (2 Form A) | |
Siemens | Chassis Mount | 70 °C | Screw Terminal | Auxiliary Contacts | 240 VAC | 208 VAC | 30 A | 600 VAC | 3PST-NO (3 Form A) | |
Siemens | Chassis Mount | 70 °C | Screw Terminal | Auxiliary Contacts | 120 VAC | 110 VAC/DC | 30 A | 600 VAC | 3PST-NO (3 Form A) | |
Siemens | Chassis Mount | 70 °C | Screw Terminal | Auxiliary Contacts | 30 A | 600 VAC | DPST-NO (2 Form A) | 24 VAC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 77.47 | |
Description
General part information
42BF Series
CONTACTOR, 42DP,30A,2P,OPEN,120V
