SRP1205-2R5Y
ObsoleteBourns Inc.
FIXED IND 2.5UH 11.5A 3.4MOHM SM
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | SRP1205-2R5Y |
|---|---|
| Current Rating (Amps) | 11.5 A |
| DC Resistance (DCR) [Max] | 3.4 mOhm |
| Frequency - Self Resonant | 40 MHz |
| Height - Seated (Max) [Max] | 0.22 in |
| Height - Seated (Max) [Max] | 5.6 mm |
| Inductance | 2.5 µH |
| Inductance Frequency - Test | 100 kHz |
| Material - Core | Ferrite |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 150 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | Nonstandard |
| Shielding | Shielded |
| Size / Dimension [x] | 0.492 in |
| Size / Dimension [x] | 12.5 mm |
| Size / Dimension [y] | 0.492 " |
| Size / Dimension [y] | 12.5 mm |
| Tolerance | 25 % |
| Type | Wirewound, Drum Core |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
SRP1205 Series
2.5 µH Shielded Drum Core, Wirewound Inductor 11.5 A 3.4mOhm Max Nonstandard
