FN332-1-05

Active

TE Connectivity Raychem Cable Protection

POWER LINE FILTER 0HZ TO 400HZ 1A 250VAC QUICK CONNECT FLANGE MOUNT

Search across all available documentation for this part.

Active

TE Connectivity Raychem Cable Protection

POWER LINE FILTER 0HZ TO 400HZ 1A 250VAC QUICK CONNECT FLANGE MOUNT

Technical Specifications

Parameters and characteristics for this part

Specification	FN332-1-05

Applications	General Purpose
Approval Agency	CSA, ENEC, UR
Configuration	Single Stage
Current	1 A
Filter Type	Single Phase
Frequency - Operating	400 Hz
Inductance	10 mH
Mounting Type	Chassis Mount
Operating Temperature [custom]	100 °C, -25 °C
Termination Style	Quick Connect
Voltage - Rated AC	250 V

Part	Filter Type	Current	Termination Style	Configuration	Applications	Voltage - Rated AC	Approval Agency	Frequency - Operating	Operating Temperature [custom]	Mounting Type	Inductance
TE Connectivity Raychem Cable Protection FN332-6-05	Single Phase	6 A	Quick Connect	Single Stage	General Purpose	250 V	CSA ENEC UR	400 Hz	-25 °C 100 °C	Chassis Mount	800 µH
TE Connectivity Raychem Cable Protection FN332-1-05	Single Phase	1 A	Quick Connect	Single Stage	General Purpose	250 V	CSA ENEC UR	400 Hz	-25 °C 100 °C	Chassis Mount	10 mH
TE Connectivity Raychem Cable Protection FN332Z-6-05	Single Phase	6 A	Terminal Post	Single Stage	General Purpose	250 V	CSA ENEC UR	400 Hz	-25 °C 100 °C	Chassis Mount	800 µH
TE Connectivity Raychem Cable Protection FN332Z-3-05	Single Phase	3 A	Terminal Post	Single Stage	General Purpose	250 V	CSA ENEC UR	400 Hz	-25 °C 100 °C	Chassis Mount	2 mH
TE Connectivity Raychem Cable Protection FN332-10A-05	Single Phase	10 A	Quick Connect	Single Stage	General Purpose	250 V	CSA ENEC UR	400 Hz	-25 °C 100 °C	Chassis Mount	500 µH

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Single Phase EMC/EMI Line Filter 1 A 250V DC ~ 400Hz Single Stage Quick Connect
