C091 11G105 000 2

Active

Amphenol Tuchel Industrial

CONN RCPT HSNG FMALE 5POS PNL MT

Search across all available documentation for this part.

Active

Amphenol Tuchel Industrial

CONN RCPT HSNG FMALE 5POS PNL MT

Technical Specifications

Parameters and characteristics for this part

Specification	C091 11G105 000 2

Connector Type	Receptacle Housing
Contact Shape	Circular
Contact Size	1.5 mm
Contact Type	Crimp
Features	Stereo
Housing Color	Silver
Ingress Protection	IP69K, IP65, IP67
Insert Material	Thermoplastic
Material Flammability Rating	UL94 V-0
Mounting Feature	Bulkhead - Front Side Nut
Note	Contacts Not Included
Operating Temperature [Max]	100 °C
Operating Temperature [Min]	-40 °C
Orientation	Keyed
Shell Finish	Nickel
Shell Material	Die Cast
Shell Size - Insert	M16-5(S)
Shielding	Shielded
Type	For Female Sockets

Part	Features	Housing Color	Ingress Protection	Contact Size	Type	Operating Temperature [Max]	Operating Temperature [Min]	Connector Type	Contact Shape	Shell Material	Shell Size - Insert	Material Flammability Rating	Contact Type	Insert Material	Shell Finish	Shielding	Note	Mounting Feature	Orientation
Amphenol Tuchel Industrial C091 11G105 000 2	Stereo	Silver	IP65 IP67 IP69K	1.5 mm	For Female Sockets	100 °C	-40 °C	Receptacle Housing	Circular	Die Cast	M16-5(S)	UL94 V-0	Crimp	Thermoplastic	Nickel	Shielded	Contacts Not Included	Bulkhead - Front Side Nut	Keyed

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

5 Position Circular Connector Receptacle Housing Panel Mount Stereo
