AH01P-12

Active

XP Power

DC DC CONVERTER 100V 1.5W

Search across all available documentation for this part.

Active

XP Power

DC DC CONVERTER 100V 1.5W

Technical Specifications

Parameters and characteristics for this part

Specification	AH01P-12

Applications	ITE (Commercial)
Approval Agency	CE, cURus
Current - Output (Max) [Max]	15 mA
Features	Proportional Output
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature [Max]	75 ░C
Operating Temperature [Min]	-25 °C
Package / Case	5-DIP Module
Power (Watts)	1.5 W
Size / Dimension [x]	23.4 mm
Size / Dimension [x]	0.92 in
Size / Dimension [y]	0.45 in
Size / Dimension [y]	11.4 mm
Size / Dimension [z]	6.4 mm
Size / Dimension [z]	0.25 "
Standard Number	62368-1
Type	High Voltage - Isolated Module
Voltage - Input (Max) [Max]	12 V
Voltage - Input (Min) [Min]	0.7 V
Voltage - Isolation	500 V
Voltage - Output 1	100 V

DC DC CONVERTER 100V 1.5W

Part	Standard Number	Voltage - Output 1	Voltage - Input (Max) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Type	Features	Number of Outputs	Approval Agency	Applications	Current - Output (Max) [Max]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Package / Case	Voltage - Isolation	Mounting Type	Voltage - Input (Min) [Min]	Power (Watts)
XP Power AH01P-12	62368-1	100 V	12 V	-25 °C	75 ░C	High Voltage - Isolated Module	Proportional Output	1	CE, cURus	ITE (Commercial)	15 mA	6.4 mm	0.45 in	23.4 mm	0.25 "	11.4 mm	0.92 in	5-DIP Module	500 V	Through Hole	0.7 V	1.5 W

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

High Voltage - Isolated Module DC DC Converter 1 Output 100V 15mA 0.7V - 12V Input
