Q-2L02L0013012i

Active

Amphenol Custom Cable

CBL ASSY NTYPE PLUG TO PLUG 12"

Deep-Dive with AI

Search across all available documentation for this part.

Q-2L02L0013012i

Active

Amphenol Custom Cable

CBL ASSY NTYPE PLUG TO PLUG 12"

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	Q-2L02L0013012i

1st Connector Mounting Type	Free Hanging (In-Line)
1st Contact Gender	Male
2nd Connector	N-Type Plug
2nd Connector Mounting Type	Free Hanging (In-Line)
2nd Contact Gender	Male
Cable Type	LMR 400
Color	Black
Features	Shielded
Frequency - Max [Max]	6000 MHz
Length	12 "
Length	304.8 mm
Overall Impedance	50 Ohms
Style	N-Type to N-Type

Q-2L02L0 Series

Part	2nd Connector	1st Contact Gender	1st Connector Mounting Type	2nd Contact Gender	Frequency - Max [Max]	2nd Connector Mounting Type	Cable Type	Length	Length	Length	Style	Color	Overall Impedance	Features	Length [x]	Length [x]	Length [x]
Amphenol Custom Cable Q-2L02L00131.5M	N-Type Plug	Male	Free Hanging (In-Line)	Male	6000 MHz	Free Hanging (In-Line)	LMR 400	59.1 in	4.9 ft	1.5 m	N-Type to N-Type	Black	50 Ohms	Shielded
Amphenol Custom Cable Q-2L02L0013.25M	N-Type Plug	Male	Free Hanging (In-Line)	Male	6000 MHz	Free Hanging (In-Line)	LMR 400				N-Type to N-Type	Black	50 Ohms	Shielded	9.843 "	250 mm
Amphenol Custom Cable Q-2L02L00132.5M	N-Type Plug	Male	Free Hanging (In-Line)	Male	6000 MHz	Free Hanging (In-Line)	LMR 400	98.4 in	8.2 '	2.5 m	N-Type to N-Type	Black	50 Ohms	Shielded
Amphenol Custom Cable Q-2L02L00130.5M	N-Type Plug	Male	Free Hanging (In-Line)	Male	6000 MHz	Free Hanging (In-Line)	LMR 400	19.69 "		50 cm	N-Type to N-Type	Black	50 Ohms	Shielded
Amphenol Custom Cable Q-2L02L0013018i	N-Type Plug	Male	Free Hanging (In-Line)	Male	6000 MHz	Free Hanging (In-Line)	LMR 400				N-Type to N-Type	Black	50 Ohms	Shielded		457.2 mm	457.2 mm
Amphenol Custom Cable Q-2L02L0013072i	N-Type Plug	Male	Free Hanging (In-Line)	Male	6000 MHz	Free Hanging (In-Line)	LMR 400	72 in	6 ft	1.8 m	N-Type to N-Type	Black	50 Ohms	Shielded
Amphenol Custom Cable Q-2L02L0013012i	N-Type Plug	Male	Free Hanging (In-Line)	Male	6000 MHz	Free Hanging (In-Line)	LMR 400	12 "		304.8 mm	N-Type to N-Type	Black	50 Ohms	Shielded
Amphenol Custom Cable Q-2L02L0013006i	N-Type Plug	Male	Free Hanging (In-Line)	Male	6000 MHz	Free Hanging (In-Line)	LMR 400	6 in		152.4 mm	N-Type to N-Type	Black	50 Ohms	Shielded
Amphenol Custom Cable Q-2L02L0013108i	N-Type Plug	Male	Free Hanging (In-Line)	Male	6000 MHz	Free Hanging (In-Line)	LMR 400	108 in	9 ft	2.7 m	N-Type to N-Type	Black	50 Ohms	Shielded
Amphenol Custom Cable Q-2L02L0013009i	N-Type Plug	Male	Free Hanging (In-Line)	Male	6000 MHz	Free Hanging (In-Line)	LMR 400	9 "		228.6 mm	N-Type to N-Type	Black	50 Ohms	Shielded

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bag	1	$ 119.12
		25	$ 116.87
		50	$ 114.63
		100	$ 112.38
		250	$ 110.14

Description

General part information

Q-2L02L0 Series

Cable Assembly Coaxial N-Type to N-Type LMR 400 12.00" (304.80mm)

Documents

Technical documentation and resources

No documents available
