88641 0021000

Active

Belden Inc.

CABLE 2COND 24AWG RED SHLD

Search across all available documentation for this part.

Active

Belden Inc.

CABLE 2COND 24AWG RED SHLD

Technical Specifications

Parameters and characteristics for this part

Specification	88641 0021000

Cable Type	Multi-Conductor
Conductor Insulation	Fluorinated Ethylene-Propylene (FEP)
Conductor Material	Copper, Tinned
Conductor Strand [custom]	32 AWG
Conductor Strand [custom]	7
Features	Drain Wire
Jacket (Insulation) Diameter [diameter]	0.106 in
Jacket (Insulation) Diameter [diameter]	2.69 mm
Jacket (Insulation) Material	Fluorinated Ethylene-Propylene (FEP), Plenum
Jacket (Insulation) Thickness	0.356 mm
Jacket (Insulation) Thickness	0.014 in
Jacket Color	Red
Length	1000 ft
Length	304.8 m
Number of Conductors	2
Operating Temperature [Max]	150 °C
Operating Temperature [Min]	-20 C
Ratings	UL Style CMP
Shield Coverage	100 %
Shield Material	Aluminum
Shield Type	Foil
Usage	Audio, Instrumentation, Control
Voltage	300 V
Wire Gauge	24 AWG

Part	Jacket (Insulation) Material	Features	Conductor Strand [custom]	Conductor Strand [custom]	Shield Material	Shield Type	Operating Temperature [Max]	Operating Temperature [Min]	Wire Gauge	Conductor Insulation	Conductor Material	Number of Conductors	Cable Type	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket Color	Shield Coverage	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Length [x]	Length [x]	Ratings	Voltage	Usage	Length	Length
Belden Inc. 88641 002100	Fluorinated Ethylene-Propylene (FEP) Plenum	Drain Wire	32 AWG	7	Aluminum	Foil	150 °C	-20 C	24 AWG	Fluorinated Ethylene-Propylene (FEP)	Copper Tinned	2	Multi-Conductor	0.106 in	2.69 mm	Red	100 %	0.356 mm	0.014 in	30.5 m	100 ft
Belden Inc. 88641 0021000	Fluorinated Ethylene-Propylene (FEP) Plenum	Drain Wire	32 AWG	7	Aluminum	Foil	150 °C	-20 C	24 AWG	Fluorinated Ethylene-Propylene (FEP)	Copper Tinned	2	Multi-Conductor	0.106 in	2.69 mm	Red	100 %	0.356 mm	0.014 in			UL Style CMP	300 V	Audio Control Instrumentation	1000 ft	304.8 m

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

2 (1 Pair Twisted) Conductor Multi-Conductor Cable Red 24 AWG Foil 1000.0' (304.8m)
