Part	Color	Number of Rows	Connector Type	Pitch	Number of Positions Loaded	Mounting Type	Features	Number of Columns	Contact Finish	Termination	Number of Positions	Differential Pairs (Typical)	Connector Style	Contact Finish Thickness	Current Rating	Voltage Rating	Operating Temperature (Min)	Operating Temperature (Max)	Material Flammability Rating
Molex 0764959107	Gray	12	Header Male Pins	0.053 in	All	Board Edge Right Angle Through Hole	Board Guide	10	Gold	Press-Fit	120	40	Guide Right Impact	30 µin	0.75 A	30 V	-55 °C	85 °C	UL94 V-0
Molex 0764951228	Black	12	Header Male Pins	0.053 in	All	Board Edge Right Angle Through Hole		12	Gold	Press-Fit	144	48	Impact	30 µin		30 V	-55 °C	85 °C	UL94 V-0
Molex 0764955607	Black	12	Header Male Pins	0.053 in	All	Board Edge Right Angle Through Hole	Guide Pin	16	Gold	Press-Fit	192	64	Guide Right Impact	30 µin		30 V	-55 °C	85 °C	UL94 V-0
Molex 0764951827	Black	12	Header Male Pins	0.053 in	All	Board Edge Right Angle Through Hole		8	Gold	Press-Fit	96	32	Impact	30 µin		30 V	-55 °C	85 °C	UL94 V-0
Molex 0764955107	Black	12	Header Male Pins	0.053 in	All	Board Edge Right Angle Through Hole	Guide Pin	10	Gold	Press-Fit	120	40	Guide Right Impact	30 µin		30 V	-55 °C	85 °C	UL94 V-0
Molex 0764951105
Molex 0764951607	Black	12	Header Male Pins	0.053 in	All	Right Angle Through Hole		16	Gold	Press-Fit	192	64	Impact	30 µin		30 V	-55 °C	85 °C	UL94 V-0
Molex 0764951807	Black	12	Header Male Pins	0.053 in	All	Board Edge Right Angle Through Hole		8	Gold	Press-Fit	96	32	Impact	30 µin		30 V	-55 °C	85 °C	UL94 V-0
Molex 0764951617	Black	12	Header Male Pins	0.053 in	All	Board Edge Right Angle Through Hole		16	Gold	Press-Fit	192	64	Impact	30 µin		30 V	-55 °C	85 °C	UL94 V-0
Molex 0764955218

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

0764951105 | Datasheet
