MEV1S0509SC

Active

Murata Power Solutions Inc.

ISOLATED THROUGH HOLE DC/DC CONVERTER, ITE, SIP, 1:1, 1 W, 1 OUTPUT, 9 V

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet Product Change Notice EN +1

MEV1S0509SC

Active

Murata Power Solutions Inc.

ISOLATED THROUGH HOLE DC/DC CONVERTER, ITE, SIP, 1:1, 1 W, 1 OUTPUT, 9 V

Deep-Dive with AI

DocumentsDatasheet Product Change Notice EN +1

Specifications Pricing Series Description Documents

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	1	$ 6.77
		5	$ 6.74
		10	$ 6.69
		25	$ 6.61
		50	$ 6.45
		100	$ 6.13
		250	$ 5.73
		500	$ 5.35
		1000	$ 5.01
Newark	Each	25	$ 7.29
		50	$ 7.12
		100	$ 6.79

Description

General part information

MEV1S05 Series

The PL2R1 series plug-in Analogue Timer offers a LED status indicator, relay output 1 or 2 and a 3-wire sensor control option. It has an option of connecting an external power supply to the control input. This series features 1 second to 100 hours timing ranges (7 ranges) and 2.5kV/1 minute/1mA/50Hz breakdown voltage according to IEC/EN 61812-1 standard. It is conformed to IEC/EN 61812-1, IEC/EN 61000-6-2, IEC/EN 61000-6-3, IEC/EN 61000-6-4 standards.

Documents

Technical documentation and resources

Datasheet

Product Change Notice EN

Datasheet

Technical Data Sheet EN

Datasheet

Specification	MEV1S0509SC	MEV1S05 Series

Applications	ITE (Commercial)	ITE (Commercial)
Current - Output (Max)	-	67 - 200 mA
Efficiency	86.5 %	84 - 87.5 %
Mounting Type	Through Hole	Through Hole
Number of Outputs	1	1
Operating Temperature [Max]	85 °C	85 °C
Operating Temperature [Min]	-40 °C	-40 °C
Package / Case	7-SIP Module, 5 Leads	7-SIP Module, 5 Leads, 6-SIP Module, 5 Leads, 14-DIP Module, 5 Leads
Size / Dimension [x]	19.7 mm	19.6 - 19.7 mm
Size / Dimension [x]	0.77 in	0.77 in
Size / Dimension [y]	6.2 mm	6.1 - 10 mm
Size / Dimension [y]	0.24 "	0.24 - 0.39 "
Size / Dimension [z]	0.4 "	0.28 - 0.4 "
Size / Dimension [z]	10.2 mm	7 - 10.2 mm
Type	Isolated Module	Isolated Module
Voltage - Input (Max) [Max]	5.5 V	5.5 V
Voltage - Input (Min) [Min]	4.5 V	4.5 V
Voltage - Isolation	3000 V	3000 V
Voltage - Output 1	9 V	5 - 15 V

Part	Current - Output (Max) [Max]	Mounting Type	Voltage - Isolation	Efficiency	Voltage - Output 1	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Type	Voltage - Input (Min) [Min]	Number of Outputs	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Input (Max) [Max]	Package / Case	Applications
Murata Power Solutions Inc. MEV1S0512SC	84 mA	Through Hole	3000 V	87 %	12 V	19.7 mm	0.4 "	6.2 mm	0.77 in	0.24 "	10.2 mm	Isolated Module	4.5 V	1	85 °C	-40 °C	5.5 V	7-SIP Module, 5 Leads	ITE (Commercial)
Murata Power Solutions Inc. MEV1S0505SC	200 mA	Through Hole	3000 V	84 %	5 V	19.6 mm	0.4 "	6.1 mm	0.77 in	0.24 "	10.2 mm	Isolated Module	4.5 V	1	85 °C	-40 °C	5.5 V	6-SIP Module, 5 Leads	ITE (Commercial)
Murata Power Solutions Inc. MEV1S0515DC	67 mA	Through Hole	3000 V	87.5 %	15 V	19.7 mm	0.28 "	10 mm	0.77 in	0.39 "	7 mm	Isolated Module	4.5 V	1	85 °C	-40 °C	5.5 V	14-DIP Module, 5 Leads	ITE (Commercial)
Murata Power Solutions Inc. MEV1S0509SC		Through Hole	3000 V	86.5 %	9 V	19.7 mm	0.4 "	6.2 mm	0.77 in	0.24 "	10.2 mm	Isolated Module	4.5 V	1	85 °C	-40 °C	5.5 V	7-SIP Module, 5 Leads	ITE (Commercial)
Murata Power Solutions Inc. MEV1S0509DC		Through Hole	3000 V	86.5 %	9 V	19.7 mm	0.28 "	10 mm	0.77 in	0.39 "	7 mm	Isolated Module	4.5 V	1	85 °C	-40 °C	5.5 V	14-DIP Module, 5 Leads	ITE (Commercial)
Murata Power Solutions Inc. MEV1S0512DC	84 mA	Through Hole	3000 V	87 %	12 V	19.7 mm	0.28 "	10 mm	0.77 in	0.39 "	7 mm	Isolated Module	4.5 V	1	85 °C	-40 °C	5.5 V	14-DIP Module, 5 Leads	ITE (Commercial)
Murata Power Solutions Inc. MEV1S0515SC	67 mA	Through Hole	3000 V	87.5 %	15 V	19.6 mm	0.4 "	6.1 mm	0.77 in	0.24 "	10.2 mm	Isolated Module	4.5 V	1	85 °C	-40 °C	5.5 V	6-SIP Module, 5 Leads	ITE (Commercial)
