AM15JW-2412SH30Z

Unknown

aimtec

DC DC CONVERTER 12V 15W

Search across all available documentation for this part.

Unknown

aimtec

DC DC CONVERTER 12V 15W

Technical Specifications

Parameters and characteristics for this part

DC DC CONVERTER 12V 15W

Part	Number of Outputs	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Type	Mounting Type	Voltage - Output 1	Applications	Current - Output (Max) [Max]	Voltage - Input (Min) [Min]	Voltage - Isolation	Package / Case	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Input (Max) [Max]	Efficiency	Power (Watts)
aimtec AM15JW-2412SH30Z	1	10.9 mm	40.6 mm	25.4 mm	0.43 "	1.6 "	25.4 mm	Isolated Module	Through Hole	12 V	ITE (Commercial)	1.25 A	9 V	3000 V	6-DIP Module	-40 °C	100 °C	36 V	88 %	15 W

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Isolated Module DC DC Converter 1 Output 12V 1.25A 9V - 36V Input
