GLF1200

Active

NANO CURRENT POWER LOAD SWITCH

Active

NANO CURRENT POWER LOAD SWITCH

Description

General part information

Power Switch/Driver P-Channel 2A SOT-23-5

Parameters and characteristics for this part

Specification	GLF1200

Current - Output (Max)	2 A
Mounting Type	Surface Mount
Operating Temperature (Max)	85 °C
Operating Temperature (Min)	-40 °C
Output Type	P-Channel
Package Name	SOT-23-5
Rds On (Typ)	54 mOhm
Switch Type	Load Switch
Voltage - Supply (Vcc/Vdd) Maximum	5.5 V
Voltage - Supply (Vcc/Vdd) Minimum	1.5 V

Part	Output Type	Voltage - Supply (Vcc/Vdd) Minimum	Voltage - Supply (Vcc/Vdd) Maximum	Mounting Type	Switch Type	Package Name	Current - Output (Max)	Operating Temperature (Max)	Operating Temperature (Min)	Rds On (Typ)
GLF Integrated Power GLF1200Q	P-Channel	1.5 V	5.5 V	Surface Mount	Load Switch	SOT-23-5	2 A	85 °C	-40 °C	60 mOhm
GLF Integrated Power GLF1200	P-Channel	1.5 V	5.5 V	Surface Mount	Load Switch	SOT-23-5	2 A	85 °C	-40 °C	54 mOhm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

3D models and CAD resources for this part

Technical documentation and resources
