Specification	5153-12-5

Adhesive	Silicone Thermosetting
Backing, Carrier	Polytetrafluoroethylene, PTFE
Color	Brown
Length (ft)	15 ft
Length (yd)	5 yd
Shelf Life	24 Months
Shelf Life Start	Date of Manufacture
Storage/Refrigeration Temperature (Maximum)	80 °F
Storage/Refrigeration Temperature (Minimum)	60 °F
Tape Type	Glass Cloth
Temperature Range (Max)	500 °F
Temperature Range (Min)	-100 °F
Thickness	0.008 in
Thickness - Adhesive	0.0022 in
Thickness - Backing, Carrier	0.0058 in
Usage	General Purpose
Width	12.7 mm

5153 Series

Part	Shelf Life Start	Storage/Refrigeration Temperature (Maximum)	Storage/Refrigeration Temperature (Minimum)	Shelf Life	Width	Thickness	Backing, Carrier	Tape Type	Length (yd)	Length (ft)	Color	Thickness - Backing, Carrier	Adhesive	Thickness - Adhesive	Temperature Range (Min)	Temperature Range (Max)	Usage
3M (TC) 3M 5153 10" X 36YD	Date of Manufacture	80 °F	60 °F	24 Months	10 in	0.008 in	Polytetrafluoroethylene PTFE	Glass Cloth	36 yd	108 ft	Brown	0.0058 in	Silicone Thermosetting	0.0022 in	-100 °F	500 °F
3M (TC) 3M 5153 7" X 36YD	Date of Manufacture	80 °F	60 °F	24 Months	7 in	0.008 in	Polytetrafluoroethylene PTFE	Glass Cloth	36 yd	108 ft	Brown	0.0058 in	Silicone Thermosetting	0.0022 in	-100 °F	500 °F
3M (TC) 3M 5153 0.438" X 36YD	Date of Manufacture	80 °F	60 °F	24 Months	0.44 in	0.008 in	Polytetrafluoroethylene PTFE	Glass Cloth	36 yd	108 ft	Brown	0.0058 in	Silicone Thermosetting	0.0022 in	-100 °F	500 °F
3M (TC) 5153-1-5	Date of Manufacture	80 °F	60 °F	24 Months	1 in	0.008 in	Polytetrafluoroethylene PTFE	Glass Cloth	5 yd	15 ft	Brown	0.0058 in	Silicone Thermosetting	0.0022 in	-100 °F	400 °F	General Purpose
3M (TC) 10-5-5153	Date of Manufacture	80 °F	60 °F	24 Months	10 in	0.008 in	Polytetrafluoroethylene PTFE	Glass Cloth	5 yd	15 ft	Brown	0.0058 in	Silicone Thermosetting	0.0022 in	-100 °F	400 °F	General Purpose
3M (TC) 3M 5153 0.71" X 36YD	Date of Manufacture	80 °F	60 °F	24 Months	0.71 in	0.008 in	Polytetrafluoroethylene PTFE	Glass Cloth	36 yd	108 ft	Brown	0.0058 in	Silicone Thermosetting	0.0022 in	-100 °F	500 °F
3M (TC) 5153-6-5	Date of Manufacture	80 °F	60 °F	24 Months	6 in	0.008 in	Polytetrafluoroethylene PTFE	Glass Cloth	5 yd	15 ft	Brown	0.0058 in	Silicone Thermosetting	0.0022 in	-100 °F	400 °F	General Purpose
3M (TC) 3M 5153 1.89" X 36YD	Date of Manufacture	80 °F	60 °F	24 Months	1.89 in	0.008 in	Polytetrafluoroethylene PTFE	Glass Cloth	36 yd	108 ft	Brown	0.0058 in	Silicone Thermosetting	0.0022 in	-100 °F	500 °F
3M (TC) 5153-2-5	Date of Manufacture	80 °F	60 °F	24 Months	2 in	0.008 in	Polytetrafluoroethylene PTFE	Glass Cloth	5 yd	15 ft	Brown	0.0058 in	Silicone Thermosetting	0.0022 in	-100 °F	400 °F	General Purpose
3M (TC) 3M 5153 0.125" X 36YD	Date of Manufacture	80 °F	60 °F	24 Months	0.13 in	0.008 in	Polytetrafluoroethylene PTFE	Glass Cloth	36 yd	108 ft	Brown	0.0058 in	Silicone Thermosetting	0.0022 in	-100 °F	500 °F
