9-6609962-3

Active

TE Connectivity Raychem Cable Protection

PWR ENT MOD RCPT IEC320-C14 PNL

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet Corcom EMI/RFI Filter Selector Chart

9-6609962-3

Active

TE Connectivity Raychem Cable Protection

PWR ENT MOD RCPT IEC320-C14 PNL

Deep-Dive with AI

DocumentsDatasheet Corcom EMI/RFI Filter Selector Chart

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	9-6609962-3

Accomodates a Fuse	True
Approval Agency	UL, VDE, CSA
Connector Style	IEC 320-C14
Connector Type	Receptacle, Male Blades - Module
Current Rating - Appliance Inlet	10 A
Filter Type	Unfiltered - Commercial
Fuse Holder, Drawer	Fuse Holder, Twin Fused
Mounting Type	Panel Mount, Snap-In
Panel Thickness [Max]	2.9 mm
Panel Thickness [Max]	0.114 in
Panel Thickness [Min]	0.79 mm
Panel Thickness [Min]	0.031 "
Termination	0.187 "
Termination	4.7 mm
Termination	Quick Connect
Voltage Rating - Appliance Inlet	120 VAC

6609962 Series

Part	Panel Thickness [Max]	Panel Thickness [Max]	Panel Thickness [Min]	Panel Thickness [Min]	Connector Style	Fuse Holder, Drawer	Filter Type	Current Rating - Appliance Inlet	Approval Agency	Connector Type	Termination	Termination	Termination	Mounting Type	Voltage Rating - Appliance Inlet	Features	Current Rating - Filter	Switch Features	Panel Cutout Dimensions
TE Connectivity Raychem Cable Protection 9-6609962-3	2.9 mm	0.114 in	0.79 mm	0.031 "	IEC 320-C14	Fuse Holder Twin Fused	Unfiltered - Commercial	10 A	CSA UL VDE	Receptacle Male Blades - Module	0.187 "	4.7 mm	Quick Connect	Panel Mount Snap-In	120 VAC
TE Connectivity Raychem Cable Protection 2-6609962-9	2.9 mm	0.114 in	0.79 mm	0.031 "	IEC 320-C14	Fuse Holder Twin Fused	Filtered (EMI RFI) - Commercial	10 A	CSA UL VDE	Receptacle Male Blades - Module	0.187 "	4.7 mm	Quick Connect	Panel Mount Snap-In	120 VAC	Voltage Selector	10 A	Switch On-Off
TE Connectivity Raychem Cable Protection 6-6609962-9	2.9 mm	0.114 in	0.79 mm	0.031 "	IEC 320-C14	Fuse Holder	Unfiltered - Commercial	10 A	CSA UL VDE	Receptacle Male Blades - Module	0.187 "	4.7 mm	Quick Connect	Panel Mount Snap-In	120 VAC	Conversion Clip Voltage Selector
TE Connectivity Raychem Cable Protection 4-6609962-9	2.9 mm	0.114 in	0.79 mm	0.031 "	IEC 320-C14	Fuse Holder Twin Fused	Filtered (EMI RFI) - Commercial	10 A	CSA UL VDE	Receptacle Male Blades - Module	0.187 "	4.7 mm	Quick Connect	Panel Mount Snap-In	120 VAC	Interconnection Block	10 A	Switch On-Off
TE Connectivity Raychem Cable Protection 5-6609962-3	2.11 mm	0.083 "	0.79 mm	0.031 "	IEC 320-C14	Fuse Holder	Unfiltered - Commercial	10 A	CSA UL VDE	Receptacle Male Blades - Module	0.187 "	4.7 mm	Quick Connect	Panel Mount Snap-In	120 VAC	Conversion Clip		Switch On-Off	Variable Size
TE Connectivity Raychem Cable Protection 1-6609962-3	2.9 mm	0.114 in	0.79 mm	0.031 "	IEC 320-C14	Fuse Holder Twin Fused	Unfiltered - Commercial	10 A	CSA UL VDE	Receptacle Male Blades - Module	0.187 "	4.7 mm	Quick Connect	Panel Mount Snap-In	120 VAC	Voltage Selector		Switch On-Off
TE Connectivity Raychem Cable Protection 1-6609962-7	2.9 mm	0.114 in	0.79 mm	0.031 "	IEC 320-C14	Fuse Holder Twin Fused	Filtered (EMI RFI) - Commercial	10 A	CSA UL VDE	Receptacle Male Blades - Module	0.187 "	4.7 mm	Quick Connect	Panel Mount Snap-In	120 VAC	Interconnection Block Voltage Selector	10 A	Switch On-Off
TE Connectivity Raychem Cable Protection 3-6609962-3	2.9 mm	0.114 in	0.79 mm	0.031 "	IEC 320-C14	Fuse Holder Twin Fused	Filtered (EMI RFI) - Commercial	10 A	CSA UL VDE	Receptacle Male Blades - Module	0.187 "	4.7 mm	Quick Connect	Panel Mount Snap-In	120 VAC	Interconnection Block Voltage Selector	10 A	Switch On-Off
TE Connectivity Raychem Cable Protection 5-6609962-7	2.9 mm	0.114 in	0.79 mm	0.031 "	IEC 320-C14	Fuse Holder Twin Fused	Filtered (EMI RFI) - Commercial	10 A	CSA UL VDE	Receptacle Male Blades - Module	0.187 "	4.7 mm	Quick Connect	Panel Mount Snap-In	120 VAC	Interconnection Block Voltage Selector	10 A
TE Connectivity Raychem Cable Protection 4-6609962-1	2.9 mm	0.114 in	0.79 mm	0.031 "	IEC 320-C14	Fuse Holder Twin Fused	Filtered (EMI RFI) - Commercial	10 A	CSA UL VDE	Receptacle Male Blades - Module	0.187 "	4.7 mm	Quick Connect	Panel Mount Snap-In	120 VAC	Interconnection Block	10 A	Switch On-Off

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 11.47
		10	$ 10.16
		25	$ 9.77
		80	$ 9.18

Description

General part information

6609962 Series

Power Entry Connector Receptacle, Male Blades - Module IEC 320-C14 Panel Mount, Snap-In
