TRAB9023NP

Active

TE Connectivity Raychem Cable Protection

RF ANT 915MHZ DOME N FEM PAN MT

Search across all available documentation for this part.

Active

TE Connectivity Raychem Cable Protection

RF ANT 915MHZ DOME N FEM PAN MT

Technical Specifications

Parameters and characteristics for this part

Part	RF Family/Standard	Frequency Group [Max]	Frequency Group [Min]	Termination	Number of Bands	Applications	Power - Max [Max]	Gain	Frequency Range [Max]	Frequency Range [Min]	Frequency (Center/Band)	Antenna Type	VSWR	Height (Max) [Max] [z]	Height (Max)	Mounting Type
TE Connectivity Raychem Cable Protection TRAB9023P	Cellular	1 GHz	300 MHz	N Type Female	1	GSM	150 W	3 dBi	928 MHz	902 MHz	915 MHz	Dome	2	2.7 in	68.58 mm
TE Connectivity Raychem Cable Protection TRAB9023NP	Cellular	1 GHz	300 MHz	N Type Female	1	GSM	100 W	3 dBi	928 MHz	902 MHz	915 MHz	Dome	2	2.7 in	68.58 mm
TE Connectivity Raychem Cable Protection TRAB9023N	Cellular	1 GHz	300 MHz	NMO	1	GSM	100 W	3 dBi	928 MHz	902 MHz	915 MHz	Dome	2	2.7 in	68.58 mm	Base Mount
TE Connectivity Raychem Cable Protection TRAB9023PT5CMMX		1 GHz	300 MHz	NMO	1		150 W	3 dBi	928 MHz	902 MHz	915 MHz	Dome		2.7 in	68.58 mm	Base Mount

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

RF ANTENNA GSM Dome N Type Female Panel Mount
