Specification	SRR6040A-1R0Y

Current - Saturation (Isat)	5.55 A
Current Rating	5 A
DC Resistance (DCR) (Max)	15 mOhm
Height - Seated (Max)	0.157 in
Inductance	1 µH
Inductance Frequency - Test	10 kHz
Material - Core	Ferrite
Mounting Type	Surface Mount
Operating Temperature (Max)	125 °C
Operating Temperature (Min)	-40 °C
Package / Case	Nonstandard, Corner Terminals
Ratings	AEC-Q200
Shielding	Shielded
Size / Dimension Length	0.264 in
Size / Dimension Width	0.264 in
Tolerance	30 %

SRR6040A Series

Part	Package / Case	Inductance	DC Resistance (DCR) (Max)	Inductance Frequency - Test	Height - Seated (Max)	Current Rating	Material - Core	Shielding	Ratings	Mounting Type	Tolerance	Operating Temperature (Max)	Operating Temperature (Min)	Current - Saturation (Isat)	Size / Dimension Width	Size / Dimension Length
Bourns Inc. SRR6040A-120M	Corner Terminals Nonstandard	12 µH	55 mOhm	10 kHz	0.157 in	1.7 A	Ferrite	Shielded	AEC-Q200	Surface Mount	20 %	125 °C	-40 °C	1.61 A	0.264 in	0.264 in
Bourns Inc. SRR6040A-390M	Corner Terminals Nonstandard	39 µH	135 mOhm	10 kHz	0.157 in	1 A	Ferrite	Shielded	AEC-Q200	Surface Mount	20 %	125 °C	-40 °C	0.94 mA	0.264 in	0.264 in
Bourns Inc. SRR6040A-180M	Corner Terminals Nonstandard	18 µH	75 mOhm	10 kHz	0.157 in	1.5 A	Ferrite	Shielded	AEC-Q200	Surface Mount	20 %	125 °C	-40 °C	1.35 A	0.264 in	0.264 in
Bourns Inc. SRR6040A-270M	Corner Terminals Nonstandard	27 µH	105 mOhm	10 kHz	0.157 in	1.2 A	Ferrite	Shielded	AEC-Q200	Surface Mount	20 %	125 °C	-40 °C	1.11 A	0.264 in	0.264 in
Bourns Inc. SRR6040A-150M	Corner Terminals Nonstandard	15 µH	60 mOhm	10 kHz	0.157 in	1.6 A	Ferrite	Shielded	AEC-Q200	Surface Mount	20 %	125 °C	-40 °C	1.51 A	0.264 in	0.264 in
Bourns Inc. SRR6040A-560M	Corner Terminals Nonstandard	56 µH	190 mOhm	10 kHz	0.157 in	0.86 A	Ferrite	Shielded	AEC-Q200	Surface Mount	20 %	125 °C	-40 °C	0.77 mA	0.264 in	0.264 in
Bourns Inc. SRR6040A-1R0Y	Corner Terminals Nonstandard	1 µH	15 mOhm	10 kHz	0.157 in	5 A	Ferrite	Shielded	AEC-Q200	Surface Mount	30 %	125 °C	-40 °C	5.55 A	0.264 in	0.264 in
Bourns Inc. SRR6040A-3R0Y	Corner Terminals Nonstandard	3 µH	21 mOhm	10 kHz	0.157 in	3.5 A	Ferrite	Shielded	AEC-Q200	Surface Mount	30 %	125 °C	-40 °C	3.33 A	0.264 in	0.264 in
Bourns Inc. SRR6040A-8R2Y	Corner Terminals Nonstandard	8.2 µH	36 mOhm	10 kHz	0.157 in	2.3 A	Ferrite	Shielded	AEC-Q200	Surface Mount	30 %	125 °C	-40 °C	2 A	0.264 in	0.264 in
Bourns Inc. SRR6040A-101M	Corner Terminals Nonstandard	100 µH	345 mOhm	10 kHz	0.157 in	650 mA	Ferrite	Shielded	AEC-Q200	Surface Mount	20 %	125 °C	-40 °C	0.57 mA	0.264 in	0.264 in

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

SRR6040A-1R0Y | Datasheet

Technical Data Sheet EN
