CMD69273P-46NF

Active

TE Connectivity Raychem Cable Protection

RF ANT 700MHZ/850MHZ MOD CAB 18"

Deep-Dive with AI

Search across all available documentation for this part.

CMD69273P-46NF

Active

TE Connectivity Raychem Cable Protection

RF ANT 700MHZ/850MHZ MOD CAB 18"

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	CMD69273P-46NF

Antenna Type	Module
Applications	WiMax™, WLAN, LTE
Features	Cable - 1.2m
Frequency (Center/Band)	2.6 GHz, 1.9 GHz, 700 MHz, 850 MHz, 2.1 GHz, 900 MHz, 1.8 GHz, 2.4 GHz
Frequency Group	Wide Band
Frequency Range [Max]	960 MHz, 2.7 GHz
Frequency Range [Min]	698 MHz, 1.71 GHz
Gain	6.8 dBi, 5.1 dBic, 6.3 dBi, 3.9 dBi, 3.8 dBi, 7.4 dB, 3.5 dBi, 4.7 dBi
Height (Max)	43.5 mm
Height (Max) [Max]	1.713 in
Number of Bands	8
Power - Max [Max]	50 W
RF Family/Standard	Cellular, WiFi
Termination	N Type Female
VSWR	2

CMD69273 Series

Part	VSWR	Gain	Mounting Type	Frequency Group	Number of Bands	Power - Max [Max]	Height (Max) [Max]	Height (Max)	Frequency (Center/Band)	Frequency Range [Max]	Frequency Range [Min]	Applications	Antenna Type	RF Family/Standard	Termination	Features	Features
TE Connectivity Raychem Cable Protection CMD69273P-30D43F	1.7	2.8 dBi	Chassis Mount	Wide Band	2	50 W	1.713 in	43.5 mm	2.2 GHz 829 MHz	2.7 GHz 960 MHz	1.71 GHz 698 MHz
TE Connectivity Raychem Cable Protection CMD69273P-FNF	2	3.5 dBi 3.8 dBi 3.9 dBi 4.7 dBi 5.1 dBic 6.3 dBi 6.8 dBi 7.4 dB		Wide Band	8	50 W	1.713 in	43.5 mm	1.8 GHz 1.9 GHz 2.1 GHz 2.4 GHz 2.6 GHz 700 MHz 850 MHz 900 MHz	2.7 GHz 960 MHz	1.71 GHz 698 MHz	LTE WiMax™ WLAN	Module	Cellular WiFi	N Type Female
TE Connectivity Raychem Cable Protection CMD69273P-46NF	2	3.5 dBi 3.8 dBi 3.9 dBi 4.7 dBi 5.1 dBic 6.3 dBi 6.8 dBi 7.4 dB		Wide Band	8	50 W	1.713 in	43.5 mm	1.8 GHz 1.9 GHz 2.1 GHz 2.4 GHz 2.6 GHz 700 MHz 850 MHz 900 MHz	2.7 GHz 960 MHz	1.71 GHz 698 MHz	LTE WiMax™ WLAN	Module	Cellular WiFi	N Type Female	Cable - 1.2m
TE Connectivity Raychem Cable Protection CMD69273P-30D41F	1.7	4.3 dBi	Chassis Mount	Wide Band	2	50 W	1.713 in	43.5 mm	2.2 GHz 829 MHz	2.7 GHz 960 MHz	1.71 GHz 698 MHz	LTE WLAN	Dome	Cellular WiFi	N Type Female	Cable	305 mm
TE Connectivity Raychem Cable Protection CMD69273-B30NF	2			Wide Band	8		1.713 in	43.5 mm		2.7 GHz 960 MHz	1.71 GHz 698 MHz	LTE WiMax™ WLAN	Module	Cellular WiFi	N Type Female	Cable	305 mm
TE Connectivity Raychem Cable Protection CMD69273P-B30D43F	2	3.5 dBi 3.8 dBi 3.9 dBi 4.7 dBi 5.1 dBic 6.3 dBi 6.8 dBi 7.4 dB	Chassis Mount	Wide Band	2	50 W	1.713 in	43.5 mm	1.8 GHz 1.9 GHz 2.1 GHz 2.4 GHz 2.6 GHz 700 MHz 850 MHz 900 MHz	2.7 GHz 960 MHz	1.71 GHz 698 MHz	LTE WLAN	Dome	Cellular WiFi	N Type Female	Cable	300 mm
TE Connectivity Raychem Cable Protection CMD69273P-B30NF	2			Wide Band	8		1.713 in	43.5 mm	1.8 GHz 1.9 GHz 2.1 GHz 2.4 GHz 2.6 GHz 700 MHz 850 MHz 900 MHz	2.7 GHz 960 MHz	1.71 GHz 698 MHz	LTE WiMax™ WLAN	Module	Cellular WiFi	N Type Female	Cable	305 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	5	$ 117.79
		10	$ 112.22
		25	$ 109.83

Description

General part information

CMD69273 Series

RF ANTENNA LTE, WiMax™, WLAN Module N Type Female Panel Mount
