T523V157M016APE0507280

Active

KEMET

CAP TANT POLY 150UF 16V 2917

Search across all available documentation for this part.

Active

KEMET

CAP TANT POLY 150UF 16V 2917

Technical Specifications

Parameters and characteristics for this part

Specification	T523V157M016APE0507280

Capacitance	150 µF
ESR (Equivalent Series Resistance)	50 mOhm
Features	General Purpose
Height - Seated (Max) [Max] [z]	1.9 mm
Height - Seated (Max) [Max] [z]	0.075 in
Lifetime @ Temp.	2000 Hrs
Manufacturer Size Code	V
Mounting Type	Surface Mount
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-55 °C
Package / Case	7343 Metric
Package / Case	2917
Size / Dimension [x]	0.287 "
Size / Dimension [x]	7.3 mm
Size / Dimension [y]	4.3 mm
Size / Dimension [y]	0.169 "
Tolerance	20 %
Type	Molded
Voltage - Rated	16 V

Part	Tolerance	Capacitance	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Features	Type	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Lifetime @ Temp.	Voltage - Rated	Manufacturer Size Code	Package / Case	Package / Case	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	ESR (Equivalent Series Resistance)
KEMET T523V157M016APE0507280	20 %	150 µF	4.3 mm	0.287 "	7.3 mm	0.169 "	General Purpose	Molded	105 ░C	-55 °C	Surface Mount	2000 Hrs	16 V	V	7343 Metric	2917	1.9 mm	0.075 in	50 mOhm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tape & Reel (TR)	3000	$ 1.34

General part information

150 µF Molded Tantalum Polymer Capacitor 16 V 2917 (7343 Metric) 50mOhm @ 100kHz
