PKE3316HPI

Active

Flex Power Modules

DC DC CONVERTER 54V 25W

Search across all available documentation for this part.

Active

Flex Power Modules

DC DC CONVERTER 54V 25W

Technical Specifications

Parameters and characteristics for this part

Specification	PKE3316HPI

Applications	ITE (Commercial)
Approval Agency	CB, UL, IEC, TUV, CSA
Control Features	Active Low, Enable
Current - Output (Max) [Max]	463 mA
Efficiency	91 %
Features	Remote On/Off, Adjustable Output
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature [Max]	110 °C
Operating Temperature [Min]	-40 °C
Package / Case	6-DIP Module
Power (Watts)	25 W
Size / Dimension [x]	25.4 mm
Size / Dimension [x]	1 in
Size / Dimension [y]	25.4 mm
Size / Dimension [y]	25.4 mm
Size / Dimension [z]	0.43 "
Size / Dimension [z]	10.8 mm
Standard Number	62368-1
Type	Isolated Module
Voltage - Input (Max) [Max]	36 V
Voltage - Input (Min) [Min]	9 V
Voltage - Isolation	1.5 kV
Voltage - Output 1	54 V

Part	Package / Case	Approval Agency	Current - Output (Max) [Max]	Mounting Type	Voltage - Input (Min) [Min]	Features	Efficiency	Type	Voltage - Output 1	Voltage - Isolation	Standard Number	Number of Outputs	Voltage - Input (Max) [Max]	Applications	Operating Temperature [Max]	Operating Temperature [Min]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Power (Watts)	Control Features	Current - Output (Max)
Flex Power Modules PKE3316ZPI	6-DIP Module	CB CSA IEC TUV UL	1.25 A	Through Hole	9 V	Adjustable Output Remote On/Off	90 %	Isolated Module	24 V	1.5 kV	62368-1	1	36 V	ITE (Commercial)	110 °C	-40 °C	25.4 mm	1 in	25.4 mm	0.43 "	10.8 mm	25.4 mm	30 W	Active Low Enable
Flex Power Modules PKE3316HPI	6-DIP Module	CB CSA IEC TUV UL	463 mA	Through Hole	9 V	Adjustable Output Remote On/Off	91 %	Isolated Module	54 V	1.5 kV	62368-1	1	36 V	ITE (Commercial)	110 °C	-40 °C	25.4 mm	1 in	25.4 mm	0.43 "	10.8 mm	25.4 mm	25 W	Active Low Enable
Flex Power Modules PKE3310PI	6-DIP Module	CB CSA IEC TUV UL		Through Hole	9 V	Adjustable Output Remote On/Off	88 %	Isolated Module	3.3 V	1.5 kV	62368-1	1	36 V	ITE (Commercial)	110 °C	-40 °C	25.4 mm	1 in	25.4 mm	0.43 "	10.8 mm	25.4 mm	23 W	Active Low Enable	7 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Isolated Module DC DC Converter 1 Output 54V 463mA 9V - 36V Input
