32410 010500

Active

Belden Inc.

HOOK-UP STRND 10AWG BLACK

Search across all available documentation for this part.

Active

Belden Inc.

HOOK-UP STRND 10AWG BLACK

Technical Specifications

Parameters and characteristics for this part

Specification	32410 010500

Cable Type	Hook-Up
Conductor Material	Copper, Tinned
Conductor Strand [custom]	22.5 AWG
Conductor Strand [custom]	19
Jacket (Insulation) Diameter [diameter]	6.05 mm
Jacket (Insulation) Diameter [diameter]	0.238 in
Jacket (Insulation) Material	Glass, Silicone
Jacket (Insulation) Thickness	0.045 in
Jacket (Insulation) Thickness	1.14 mm
Jacket Color	Black
Length [x]	500 '
Length [x]	152.4 m
Ratings	UL Style 3075
Voltage	600 V
Wire Gauge	10 AWG

Part	Voltage	Jacket Color	Cable Type	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Ratings	Length [x]	Length [x]	Wire Gauge	Conductor Strand [custom]	Conductor Strand [custom]	Jacket (Insulation) Material	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Conductor Material
Belden Inc. 32410 010500	600 V	Black	Hook-Up	6.05 mm	0.238 in	UL Style 3075	500 '	152.4 m	10 AWG	22.5 AWG	19	Glass Silicone	0.045 in	1.14 mm	Copper Tinned
Belden Inc. 32410 009500	600 V		Hook-Up	6.05 mm	0.238 in	UL Style 3075	500 '	152.4 m	10 AWG	22.5 AWG	19	Glass Silicone	0.045 in	1.14 mm	Copper Tinned

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	500	$ 4.10

General part information

10 AWG Hook-Up Wire 19/22.5 Black 600V 500.0' (152.4m)

Technical documentation and resources
