ELD107M450AR2AA

Active

KEMET

CAP ALUM 100UF 20% 450V SNAP TH

Search across all available documentation for this part.

Active

KEMET

CAP ALUM 100UF 20% 450V SNAP TH

Technical Specifications

Parameters and characteristics for this part

Specification	ELD107M450AR2AA

Applications	General Purpose
Capacitance	100 µF
ESR (Equivalent Series Resistance)	3.316 Ohm
Lead Spacing	0.394 in
Lead Spacing	10 mm
Lifetime @ Temp.	3000 Hrs
Mounting Type	Through Hole
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-25 °C
Package / Case	Radial, Can - Snap-In
Polarization	Polar
Ripple Current @ High Frequency	1.19 A
Ripple Current @ Low Frequency	850 mA
Size / Dimension [diameter]	25 mm
Size / Dimension [diameter]	0.984 "
Tolerance	20 %
Voltage - Rated	450 V

Part	Size / Dimension [diameter]	Size / Dimension [diameter]	Applications	Polarization	Ripple Current @ Low Frequency	Package / Case	Tolerance	Lead Spacing	Lead Spacing	ESR (Equivalent Series Resistance)	Mounting Type	Lifetime @ Temp.	Capacitance	Ripple Current @ High Frequency	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Rated
KEMET ELD107M450AR2AA	25 mm	0.984 "	General Purpose	Polar	850 mA	Radial Can - Snap-In	20 %	0.394 in	10 mm	3.316 Ohm	Through Hole	3000 Hrs	100 µF	1.19 A	-25 °C	105 ░C	450 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1000	$ 1.80
Newark	Each	1000	$ 1.83
		2500	$ 1.70

General part information

100 µF 450 V Aluminum Electrolytic Capacitors Radial, Can - Snap-In 3.316Ohm @ 120Hz 3000 Hrs @ 105°C
