AA15D0512A

Obsolete

Delta Electronics

AC/DC CONVERTER 5V 12V 15W

Search across all available documentation for this part.

Obsolete

Delta Electronics

AC/DC CONVERTER 5V 12V 15W

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	AA15D0512A	AA15D Series

Applications	ITE (Commercial)	ITE (Commercial)
Approval Agency	cUL, UL, CE	cUL, UL, CE
Current - Output (Max)	625 mA	625 - 650 mA
Current - Output (Max)	1.5 A	1.5 A
Current - Output (Max)	-	650 mA
Efficiency	72 %	72 - 79 %
Features	Universal Input	Universal Input
Line Regulation	0.5 %	0.5 %
Load Regulation	2.5 %	2.5 %
Mounting Type	Through Hole	Through Hole
Number of Outputs	2	2
Operating Temperature [Max]	70 °C	70 °C
Operating Temperature [Min]	-25 °C	-25 °C
Package / Case	7-DIP Module, 6 Leads	7-DIP Module, 5 Leads, 7-DIP Module, 6 Leads
Power (Watts)	15 W	15 W
Size / Dimension [x]	74 mm	74 mm
Size / Dimension [x]	2.91 "	2.91 "
Size / Dimension [y]	54 mm	54 mm
Size / Dimension [y]	2.13 in	2.13 in
Size / Dimension [z]	0.77 "	0.77 "
Size / Dimension [z]	19.5 mm	19.5 mm
Standard Number	60950-1	60950-1
Type	Enclosed	Enclosed
Voltage - Output 1	5 V	5 - 12 V
Weight	161.93 g	161.93 g
Weight	0.357 lb	0.357 lb

AC/DC CONVERTER +/-12V 15W

Part	Approval Agency	Voltage - Output 1	Power (Watts)	Line Regulation	Type	Number of Outputs	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Applications	Package / Case	Features	Current - Output (Max)	Current - Output (Max)	Weight	Weight	Efficiency	Load Regulation	Standard Number	Current - Output (Max)
Delta Electronics AA15D1212A	CE, cUL, UL	12 V	15 W	0.5 %	Enclosed	2	Through Hole	-25 °C	70 °C	74 mm	2.91 "	0.77 "	19.5 mm	54 mm	2.13 in	ITE (Commercial)	7-DIP Module, 5 Leads	Universal Input	650 mA	650 mA	161.93 g	0.357 lb	79 %	2.5 %	60950-1
Delta Electronics AA15D0512A	CE, cUL, UL	5 V	15 W	0.5 %	Enclosed	2	Through Hole	-25 °C	70 °C	74 mm	2.91 "	0.77 "	19.5 mm	54 mm	2.13 in	ITE (Commercial)	7-DIP Module, 6 Leads	Universal Input		625 mA	161.93 g	0.357 lb	72 %	2.5 %	60950-1	1.5 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Enclosed AC DC Converters 2 Output 5V 1.5A, 625mA 85 ~ 264 VAC Input
