AG5FCE

Active

AMPHENOL AUDIO

CONN PLUG FMALE MINI XLR 5P SLDR

Search across all available documentation for this part.

Active

AMPHENOL AUDIO

CONN PLUG FMALE MINI XLR 5P SLDR

Technical Specifications

Parameters and characteristics for this part

Specification	AG5FCE

Applications	Audio
Color	Silver
Connector Type	Female Sockets, Plug
Contact Finish - Mating	Gold
Contact Material	Brass
Current Rating (Amps)	5 A
Fastening Type	Latch Lock
Ingress Protection	IP40
Insert Material	Polyphenylene Sulfide (PPS)
Material Flammability Rating	UL94 HB
Mounting Feature	Bulkhead - Front Side Nut
Operating Temperature [Max]	80 C
Operating Temperature [Min]	-30 ░C
Orientation	Keyed
Primary Material	Metal
Shell Finish	Nickel
Shell Material	Brass
Shell Size - Insert	Mini XLR
Shielding	Unshielded

CONN PLUG FMALE MINI XLR 5P SLDR

Part	Shell Material	Operating Temperature [Min]	Operating Temperature [Max]	Shell Size - Insert	Material Flammability Rating	Orientation	Ingress Protection	Fastening Type	Color	Applications	Primary Material	Current Rating (Amps)	Contact Finish - Mating	Shielding	Connector Type	Contact Material	Shell Finish	Mounting Feature	Insert Material
AMPHENOL AUDIO AG5FCE	Brass	-30 ░C	80 C	Mini XLR	UL94 HB	Keyed	IP40	Latch Lock	Silver	Audio	Metal	5 A	Gold	Unshielded	Female Sockets, Plug	Brass	Nickel	Bulkhead - Front Side Nut	Polyphenylene Sulfide (PPS)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1000	$ 9.96

General part information

5 Position Circular Connector Plug, Female Sockets Solder Cup
