135113-01-12.00

Active

Amphenol RF

CBL ASSY SMA JACK TO JACK 12"

Search across all available documentation for this part.

Active

Amphenol RF

CBL ASSY SMA JACK TO JACK 12"

Technical Specifications

Parameters and characteristics for this part

Specification	135113-01-12.00

1st Connector	SMA Jack
1st Connector Mounting Feature	Bulkhead - Front Side Nut
1st Connector Mounting Type	Panel Mount
1st Contact Gender	Female
2nd Connector	SMA Jack
2nd Connector Mounting Feature	Bulkhead - Front Side Nut
2nd Connector Mounting Type	Panel Mount
2nd Contact Gender	Female
Cable Impedance	50 Ohms
Cable Type	RG-316
Color	Black
Features	Shielded
Length	12 "
Length	304.8 mm
Overall Impedance	50 Ohms
Style	SMA to SMA

Part	1st Connector Mounting Feature	2nd Connector Mounting Type	2nd Connector Mounting Feature	Features	Style	Cable Impedance	Overall Impedance	Color	1st Contact Gender	1st Connector	2nd Connector	Length	Length	Cable Type	2nd Contact Gender	1st Connector Mounting Type
Amphenol RF 135113-01-06.00	Bulkhead - Front Side Nut	Panel Mount	Bulkhead - Front Side Nut	Shielded	SMA to SMA	50 Ohms	50 Ohms	Black	Female	SMA Jack	SMA Jack	152.4 mm	6 in	RG-316	Female	Panel Mount
Amphenol RF 135113-01-12.00	Bulkhead - Front Side Nut	Panel Mount	Bulkhead - Front Side Nut	Shielded	SMA to SMA	50 Ohms	50 Ohms	Black	Female	SMA Jack	SMA Jack	304.8 mm	12 "	RG-316	Female	Panel Mount

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bag	25	$ 21.46

General part information

Cable Assembly Coaxial SMA to SMA RG-316 12.00" (304.80mm)
