Specification	1011346CH

Applications	ITE (Commercial), Medical
Approval Agency	cURus, UKCA, TUV, CE
Current - Output 1	9.2 A
Efficiency	87 %
Features	Universal Input, Adjustable Output, Remote Sense
Minimum Load Required	No
Mounting Type	Chassis Mount
Number of Outputs	1
Operating Temperature (Max)	70 °C
Operating Temperature (Min)	0 °C
Power (Watts)	110 W
Size / Dimension Height	1.5 in
Size / Dimension Length	5.25 in
Size / Dimension Width	3.25 in
Standard Number	60601-1, 62368-1
Type	Chassis
Voltage - Input (AC) Maximum	264 V
Voltage - Input (AC) Minimum	85 VAC
Voltage - Output 1	12 V

GRN-110 Series

Part	Voltage - Input (AC) Minimum	Voltage - Input (AC) Maximum	Approval Agency	Number of Outputs	Applications	Operating Temperature (Max)	Standard Number	Voltage - Output 1	Voltage - Output 2	Size / Dimension Length	Size / Dimension Height	Size / Dimension Width	Current - Output 1	Current - Output 3	Type	Current - Output 2	Power (Watts)	Voltage - Output 3	Features	Efficiency	Mounting Type	Minimum Load Required	Voltage - Output 4	Current - Output 4
Integrated Power Designs 1011376CH	85 VAC	264 V	CE cURus TUV UKCA	3	ITE (Commercial) Medical	70 °C	60601-1 62368-1	5 V	15 V	5.25 in	1.5 in	3.25 in	12 A	3 A	Chassis	3 A	150 W	-15 V	Adjustable Output Remote Sense Universal Input	85 %	Chassis Mount	No
Integrated Power Designs 1011375CH	85 VAC	264 V	CE cURus TUV UKCA	3	ITE (Commercial) Medical	70 °C	60601-1 62368-1	5 V	12 V	5.25 in	1.5 in	3.25 in	12 A	3 A	Chassis	3 A	132 W	-12 V	Adjustable Output Remote Sense Universal Input	85 %	Chassis Mount	No
Integrated Power Designs 1011243CH	85 VAC	264 V	CE cURus TUV UKCA	4	ITE (Commercial) Medical	70 °C	60601-1 62368-1	5 V	24 V	5.25 in	1.5 in	3.25 in	10 A	2 A	Chassis	2 A	110 W	12 V	Adjustable Output Remote Sense Universal Input	85 %	Chassis Mount	No	-12 V	2 A
Integrated Power Designs 1011244CHCO	85 VAC	264 V	CE cURus TUV UKCA	4	ITE (Commercial) Medical	70 °C	60601-1 62368-1	5 V	24 V	5.25 in	1.5 in	3.25 in	10 A	2 A	Enclosed	2 A	110 W	15 V	Adjustable Output Remote Sense Universal Input	85 %	Chassis Mount	No	-15 V	2 A
Integrated Power Designs 1011373CHCO	85 VAC	264 V	CE cURus TUV UKCA	4	ITE (Commercial) Medical	70 °C	60601-1 62368-1	5 V	24 V	5.25 in	1.5 in	3.25 in	10 A	2 A	Enclosed	2 A	110 W	12 V	Adjustable Output Remote Sense Universal Input	85 %	Chassis Mount	No	-12 V	2 A
Integrated Power Designs 1011245CH	85 VAC	264 V	CE cURus TUV UKCA	3	ITE (Commercial) Medical	70 °C	60601-1 62368-1	5 V	12 V	5.25 in	1.5 in	3.25 in	12 A	3 A	Chassis	3 A	110 W	-12 V	Adjustable Output Remote Sense Universal Input	85 %	Chassis Mount	No
Integrated Power Designs 1011241CH	85 VAC	264 V	CE cURus TUV UKCA	4	ITE (Commercial) Medical	70 °C	60601-1 62368-1	3.3 V	5 V	5.25 in	1.5 in	3.25 in	10 A	2 A	Chassis	5 A	110 W	12 V	Adjustable Output Remote Sense Universal Input	85 %	Chassis Mount	No	-12 V	2 A
Integrated Power Designs 1011411CHCO	85 VAC	264 V	CE cURus TUV UKCA	1	ITE (Commercial) Medical	70 °C	60601-1 62368-1	12 V		5.25 in	1.5 in	3.25 in	9.2 A		Enclosed		110 W		Adjustable Output Remote Sense Universal Input	87 %	Chassis Mount	No
Integrated Power Designs 1011372CH	85 VAC	264 V	CE cURus TUV UKCA	4	ITE (Commercial) Medical	70 °C	60601-1 62368-1	5 V	-5 V	5.25 in	1.5 in	3.25 in	10 A	2 A	Chassis	5 A	123 W	12 V	Adjustable Output Remote Sense Universal Input	85 %	Chassis Mount	No	-12 V	2 A
Integrated Power Designs 1011245CHCO	85 VAC	264 V	CE cURus TUV UKCA	3	ITE (Commercial) Medical	70 °C	60601-1 62368-1	5 V	12 V	5.25 in	1.5 in	3.25 in	12 A	3 A	Enclosed	3 A	132 W	-12 V	Adjustable Output Remote Sense Universal Input	85 %	Chassis Mount	No

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

1011346CH | Datasheet
