F280A4-113-D0510

Active

NMB TECHNOLOGIES

FAN IMP MTRZD 280X128.7MM 24VDC

Search across all available documentation for this part.

Active

NMB TECHNOLOGIES

FAN IMP MTRZD 280X128.7MM 24VDC

Technical Specifications

Parameters and characteristics for this part

Specification	F280A4-113-D0510

Air Flow	26.32 m³/min
Air Flow	940 CFM
Bearing Type	Ball
Current Rating (Amps)	3.9 A
Fan Type	Motorized Impellers
Features	Speed Sensor (Tach), PWM Control
Lifetime @ Temp.	70000 Hrs
Material - Blade	Aluminum
Operating Temperature [Max] [custom]	70 °C
Operating Temperature [Max] [custom]	158 °F
Operating Temperature [Min] [custom]	-30 °C
Operating Temperature [Min] [custom]	-22 °F
Power (Watts)	93.6 W
RPM	1700 RPM
Size / Dimension	Round
Size / Dimension [diameter]	280 mm
Static Pressure	1.206 in H2O
Static Pressure	300.4 Pa
Termination	4 Wire Leads
Voltage - Rated	24 VDC
Voltage Range [Max]	30 V
Voltage Range [Min]	18 VDC
Weight	2.1 kg
Weight	4.6 lbs
Width [y]	128.7 mm

Part	Weight	Weight	Width [y]	Power (Watts)	Voltage - Rated	Termination	Air Flow	Air Flow	Fan Type	Current Rating (Amps)	Bearing Type	Size / Dimension	Size / Dimension [diameter]	Operating Temperature [Min] [custom]	Operating Temperature [Min] [custom]	Operating Temperature [Max] [custom]	Operating Temperature [Max] [custom]	Lifetime @ Temp.	Static Pressure	Static Pressure	Features	Material - Blade	RPM	Voltage Range [Min]	Voltage Range [Max]
NMB TECHNOLOGIES F280A4-113-D0510	2.1 kg	4.6 lbs	128.7 mm	93.6 W	24 VDC	4 Wire Leads	26.32 m³/min	940 CFM	Motorized Impellers	3.9 A	Ball	Round	280 mm	-30 °C	-22 °F	70 °C	158 °F	70000 Hrs	1.206 in H2O	300.4 Pa	PWM Control Speed Sensor (Tach)	Aluminum	1700 RPM	18 VDC	30 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	10	$ 285.08
Newark	Each	1	$ 409.27
		100	$ 378.58

General part information

Fan Motorized Impellers 24VDC Round - 280mm Dia Ball 940.0 CFM (26.32m³/min) 4 Wire Leads
