C44HLGP6100AASJ

Active

KEMET

CAP FILM 100UF 5% 700VDC RADIAL

Search across all available documentation for this part.

Active

KEMET

CAP FILM 100UF 5% 700VDC RADIAL

Technical Specifications

Parameters and characteristics for this part

Specification	C44HLGP6100AASJ

Applications	Commutation, Power Factor Correction (PFC)
Capacitance	100 µF
Dielectric Material	Metallized, Polypropylene (PP)
Features	Long Life
Height - Seated (Max) [Max]	3.937 in
Height - Seated (Max) [Max]	100 mm
Lead Spacing	22.5 mm
Lead Spacing	0.886 in
Mounting Type	Chassis, Stud Mount
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-25 °C
Package / Case	Radial, Can
Size / Dimension [diameter]	65 mm
Size / Dimension [diameter]	2.559 in
Termination	Threaded, Male
Tolerance	5 %
Voltage Rating - AC	330 V
Voltage Rating - DC	700 VDC

Part	Operating Temperature [Max]	Operating Temperature [Min]	Voltage Rating - AC	Dielectric Material	Voltage Rating - DC	Termination	Lead Spacing	Lead Spacing	Applications	Size / Dimension [diameter]	Size / Dimension [diameter]	Tolerance	Package / Case	Features	Capacitance	Mounting Type	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]
KEMET C44HLGP6100AASJ	70 °C	-25 °C	330 V	Metallized Polypropylene (PP)	700 VDC	Threaded Male	22.5 mm	0.886 in	Commutation Power Factor Correction (PFC)	65 mm	2.559 in	5 %	Radial Can	Long Life	100 µF	Chassis Stud Mount	3.937 in	100 mm
KEMET C44HLGR6400AASJ	70 °C	-25 °C	330 V	Metallized Polypropylene (PP)	700 VDC	Threaded Male	35 mm	1.378 "	Commutation Power Factor Correction (PFC)	75 mm	2.953 in	5 %	Radial Can	Long Life	400 µF	Chassis Stud Mount			244 mm	9.606 in

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	15	$ 52.86

General part information

100 µF Film Capacitor 330V 700V Polypropylene (PP), Metallized Radial, Can
