111-00925

Active

HELLERMANNTYTON

CBL TIE LOCKING BLK 250LB 1.855'

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

111-00925

Active

HELLERMANNTYTON

CBL TIE LOCKING BLK 250LB 1.855'

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	111-00925	111-00 Series

Bundle Diameter	-	1.38 - 1.97 in
Bundle Diameter	-	35 - 50 mm
Bundle Diameter [diameter]	150 mm	22 - 150 mm
Bundle Diameter [diameter]	5.91 "	0.86 - 5.91 "
Color	Black	Blue, Brown, Red, Black
Features	UV Resistant	Halogen Free, UV Resistant, Heat Stabilized, Impact Resistant
Length - Actual	-	0.328 - 1.28 ft
Length - Actual	-	100 - 390 mm
Length - Actual	-	5.91 - 7.95 "
Length - Actual	-	3.93 - 7.87 "
Length - Actual [x]	565.3 mm	150 - 565.3 mm
Length - Actual [x]	1.855 ft	0.492 - 1.855 ft
Length - Approximate	22.25 in	4 - 22.25 in
Length - Approximate	-	6 in
Material	Polyamide (PA66), Nylon 6/6	Polyamide (PA66), Metal Detectable, Nylon 6/6, Polyamide (PA46), Nylon 4/6, Ethylenterafluorineethylene (ETFE), Polyamide (PA66), Nylon 6/6
Mounting Type	Free Hanging (In-Line)	Free Hanging (In-Line)
Tensile Strength	250 lbs	18 - 250 lbs
Tensile Strength	113.4 kg	8.16 - 113.4 kg
Width	12.5 mm	8.89 - 12.5 mm
Width	-	0.138 - 0.181 in
Width	-	3.5 - 4.6 mm
Width	-	2.5 - 4.7 mm
Width [x]	0.492 in	0.098 - 0.492 in
Wire/Cable Tie Type	Standard, Locking	Standard, Locking

111-00 Series

CBL TIE LOCKING BLUE 50LBS 1.28'

Part	Features	Length - Approximate	Length - Actual	Length - Actual	Wire/Cable Tie Type	Material	Mounting Type	Tensile Strength	Tensile Strength	Bundle Diameter [diameter]	Bundle Diameter [diameter]	Width [y]	Width [y]	Color	Width	Width [x]	Length - Actual [x]	Length - Actual [x]	Length - Approximate [x]	Bundle Diameter	Bundle Diameter	Length - Actual [x]	Width [x]	Length - Actual
HELLERMANNTYTON 111-00831	Halogen Free	15.25 in	1.28 ft	390 mm	Locking, Standard	Metal Detectable, Nylon 6/6, Polyamide (PA66)	Free Hanging (In-Line)	22.68 kg	50 lbs	110 mm	4.33 "	0.181 in	4.6 mm	Blue
HELLERMANNTYTON 111-00965		20.75 in			Locking, Standard	Polyamide (PA46), Nylon 4/6	Free Hanging (In-Line)	79.4 kg	175 lbs	150 mm	5.91 "			Brown	8.89 mm	0.35 in	530 mm	1.739 ft
HELLERMANNTYTON 111-00829	Halogen Free				Locking, Standard	Metal Detectable, Nylon 6/6, Polyamide (PA66)	Free Hanging (In-Line)	13.61 kg	30 lbs			0.138 "	3.5 mm	Blue			150 mm	0.492 ft	6 in	1.38 in	35 mm	5.91 "
HELLERMANNTYTON 111-00718		15 in			Locking, Standard	Ethylenterafluorineethylene (ETFE)	Free Hanging (In-Line)	22.68 kg	50 lbs	104.9 mm	4.13 in			Blue		0.185 in							4.7 mm
HELLERMANNTYTON 111-00468	UV Resistant	8 in			Locking, Standard	Polyamide (PA66), Nylon 6/6	Free Hanging (In-Line)	22.68 kg	50 lbs			0.181 in	4.6 mm	Red			202 mm	0.663 ft		1.97 in	50 mm	7.95 "
HELLERMANNTYTON 111-00732		7.75 in	0.656 ft	200 mm	Locking, Standard	Ethylenterafluorineethylene (ETFE)	Free Hanging (In-Line)	22.68 kg	50 lbs			0.181 in	4.6 mm	Blue						1.97 in	50 mm			7.87 "
HELLERMANNTYTON 111-00830	Halogen Free	7.75 in	0.656 ft	200 mm	Locking, Standard	Metal Detectable, Nylon 6/6, Polyamide (PA66)	Free Hanging (In-Line)	22.68 kg	50 lbs			0.181 in	4.6 mm	Blue						1.97 in	50 mm			7.87 "
HELLERMANNTYTON 111-00698					Locking, Standard	Ethylenterafluorineethylene (ETFE)	Free Hanging (In-Line)	13.61 kg	30 lbs			0.138 "	3.5 mm	Blue			150 mm	0.492 ft	6 in	1.42 in	36 mm	5.91 "
HELLERMANNTYTON 111-00659		4 in	0.328 ft	100 mm	Locking, Standard	Ethylenterafluorineethylene (ETFE)	Free Hanging (In-Line)	8.16 kg	18 lbs	22 mm	0.86 in			Blue		0.098 in							2.5 mm	3.93 in
HELLERMANNTYTON 111-00925	UV Resistant	22.25 in			Locking, Standard	Polyamide (PA66), Nylon 6/6	Free Hanging (In-Line)	113.4 kg	250 lbs	150 mm	5.91 "			Black	12.5 mm	0.492 in	565.3 mm	1.855 ft

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	25	$ 2.28
		50	$ 2.11
		75	$ 2.02
		125	$ 1.91
		175	$ 1.84
		250	$ 1.77
		625	$ 1.61
		1250	$ 1.50
		2500	$ 1.40

Description

General part information

111-00 Series

Standard, Locking Black 5.91" (150.00mm) 0.492" (12.50mm) 250 lbs (113.40 kg)

Documents

Technical documentation and resources
