DA103JC
ActiveMurata Power Solutions Inc.
DIGITAL AUDIO TX 1:1 5MH DIP
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
DA103JC
ActiveMurata Power Solutions Inc.
DIGITAL AUDIO TX 1:1 5MH DIP
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | DA103JC | DA103 Series |
|---|---|---|
| - | - | |
| ET (Volt-Time) | 28 VµS | 28 VµS |
| Height - Seated (Max) | 6.35 mm | 6.35 mm |
| Height - Seated (Max) [Max] | 0.25 in | 0.25 in |
| Inductance | 7.75 mH | 7.75 mH |
| Mounting Type | Surface Mount | Surface Mount |
| Operating Temperature [Max] | 85 °C | 70 - 85 °C |
| Operating Temperature [Min] | -40 °C | -40 - 0 °C |
| Turns Ratio - Primary:Secondary | 1:1 | 1:1 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
DA103 Series
AUDIO TRANSFORMER 1:1 2000VRMS 6 TERMINAL GULL WING SMD
| Part | Height - Seated (Max) | Height - Seated (Max) [Max] | Mounting Type | Turns Ratio - Primary:Secondary | Inductance | Operating Temperature [Max] | Operating Temperature [Min] | ET (Volt-Time) |
|---|---|---|---|---|---|---|---|---|
Murata Power Solutions Inc. DA103MC-R | ||||||||
Murata Power Solutions Inc. DA103MC-R | 6.35 mm | 0.25 in | Surface Mount | 1:1 | 7.75 mH | 70 °C | 0 °C | 28 VµS |
Murata Power Solutions Inc. DA103MC-R | ||||||||
Murata Power Solutions Inc. DA103JC | 6.35 mm | 0.25 in | Surface Mount | 1:1 | 7.75 mH | 85 °C | -40 °C | 28 VµS |
Murata Power Solutions Inc. DA103JC |
Description
General part information
DA103 Series
7.75mH Pulse Transformer 1:1 Surface Mount
