SMI24-5-K-P6R

Active

CUI Inc.

AC/DC WALL MOUNT ADAPTER 5V 20W

Deep-Dive with AI

Search across all available documentation for this part.

SMI24-5-K-P6R

Active

CUI Inc.

AC/DC WALL MOUNT ADAPTER 5V 20W

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	SMI24-5-K-P6R

Applications	ITE (Commercial)
Approval Agency	CCC, EN, RCM, UL, IEC, PSE, CSA, CB Scheme
Cord Length	1 m
Cord Length	39.4 "
Current - Output (Max) [Max]	4 A
Efficiency	CoC Tier 2, Level VI
Form	Wall Mount (Class II)
Input Connector	Multi-Blade
Input Type	Multi-Blade (Sold Separately)
No Load Power Consumption	100 mW
Operating Temperature [Max]	40 °C
Operating Temperature [Min]	0 °C
Output Connector	Barrel Plug R/A
Output Connector [diameter]	5.5 mm, 2.5 mm
Output Connector [x]	9.5 mm
Polarization	Positive Center
Power (Watts)	20 W
Region Utilized	International
Size / Dimension [x]	2.95 in
Size / Dimension [x]	75 mm
Size / Dimension [y]	1.38 "
Size / Dimension [y]	35 mm
Size / Dimension [z]	2.58 "
Size / Dimension [z]	65.6 mm
Standard Number	C22.2 No. 60950-1, 55024, 62368-1, 60950-1, 61000-3-3, 55032 Class B, 61000-3-2
Voltage - Input [Max]	264 VAC
Voltage - Input [Min]	90 VAC
Voltage - Output	5 V
Weight	0.349 lb
Weight	158.3 g

SMI24 Series

Part	Operating Temperature [Max]	Polarization	Output Connector [x]	Output Connector [diameter]	Output Connector	Applications	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Cord Length	Cord Length	Standard Number	Input Connector	Input Type	No Load Power Consumption	Form	Current - Output (Max) [Max]	Region Utilized	Approval Agency	Voltage - Output	Weight	Weight	Efficiency	Voltage - Input [Min]	Voltage - Input [Max]	Power (Watts)	Output Connector [z]	Output Connector [y]
CUI Inc. SMI24-5-K-P6R	40 °C	Positive Center	9.5 mm	2.5 mm 5.5 mm	Barrel Plug R/A	ITE (Commercial)	2.58 "	2.95 in	75 mm	1.38 "	65.6 mm	35 mm	1 m	39.4 "	55024 55032 Class B 60950-1 61000-3-2 61000-3-3 62368-1 C22.2 No. 60950-1	Multi-Blade	Multi-Blade (Sold Separately)	100 mW	Wall Mount (Class II)	4 A	International	CB Scheme CCC CSA EN IEC PSE RCM UL	5 V	0.349 lb	158.3 g	CoC Tier 2 Level VI	90 VAC	264 VAC	20 W
CUI Inc. SMI24-48-V-P6	40 °C	Positive Center	9.5 mm	2.5 mm 5.5 mm	Barrel Plug	ITE (Commercial)	2.58 "	2.95 in	75 mm	1.38 "	65.6 mm	35 mm	1.5 m	59 in	55024 55032 Class B 60950-1 61000-3-2 61000-3-3 62368-1 C22.2 No. 60950-1	Multi-Blade	Multi-Blade (Included)	100 mW	Wall Mount (Class II)	500 mA	International	CB Scheme CCC CSA EN IEC PSE RCM UL	48 V	0.349 lb	158.3 g	CoC Tier 2 Level VI	90 VAC	264 VAC	24 W
CUI Inc. SMI24-12-K-P5	40 °C	Positive Center	9.5 mm	2.1 mm 5.5 mm	Barrel Plug	ITE (Commercial)	2.58 "	2.95 in	75 mm	1.38 "	65.6 mm	35 mm	1.5 m	59 in	55024 55032 Class B 60950-1 61000-3-2 61000-3-3 62368-1 C22.2 No. 60950-1	Multi-Blade	Multi-Blade (Sold Separately)	100 mW	Wall Mount (Class II)	2 A	International	CB Scheme CCC CSA EN IEC PSE RCM UL	12 V	0.349 lb	158.3 g	CoC Tier 2 Level VI	90 VAC	264 VAC	24 W
CUI Inc. SMI24-9-V-P5R	40 °C	Positive Center	2.1 mm		Barrel Plug R/A	ITE (Commercial)	2.58 "	2.95 in	75 mm	1.38 "	65.6 mm	35 mm	1.5 m	59 in	55024 55032 Class B 60950-1 61000-3-2 61000-3-3 62368-1 C22.2 No. 60950-1	Multi-Blade	Multi-Blade (Included)	100 mW	Wall Mount (Class II)	2.5 A	International	CB Scheme CCC CSA EN IEC PSE RCM UL	9 V	0.349 lb	158.3 g	CoC Tier 2 Level VI	90 VAC	264 VAC	23 W	9.5 mm	5.5 mm
CUI Inc. SMI24-24-K-P5R	40 °C	Positive Center	2.1 mm		Barrel Plug R/A	ITE (Commercial)	2.58 "	2.95 in	75 mm	1.38 "	65.6 mm	35 mm	1.5 m	59 in	55024 55032 Class B 60950-1 61000-3-2 61000-3-3 62368-1 C22.2 No. 60950-1	Multi-Blade	Multi-Blade (Sold Separately)	100 mW	Wall Mount (Class II)	1 A	International	CB Scheme CCC CSA EN IEC PSE RCM UL	24 V	0.349 lb	158.3 g	CoC Tier 2 Level VI	90 VAC	264 VAC	24 W	9.5 mm	5.5 mm
CUI Inc. SMI24-9-V-P6R	40 °C	Positive Center	9.5 mm	2.5 mm 5.5 mm	Barrel Plug R/A	ITE (Commercial)	2.58 "	2.95 in	75 mm	1.38 "	65.6 mm	35 mm	1.5 m	59 in	55024 55032 Class B 60950-1 61000-3-2 61000-3-3 62368-1 C22.2 No. 60950-1	Multi-Blade	Multi-Blade (Included)	100 mW	Wall Mount (Class II)	2.5 A	International	CB Scheme CCC CSA EN IEC PSE RCM UL	9 V	0.349 lb	158.3 g	CoC Tier 2 Level VI	90 VAC	264 VAC	23 W
CUI Inc. SMI24-24-V-P5R	40 °C	Positive Center	2.1 mm		Barrel Plug R/A	ITE (Commercial)	2.58 "	2.95 in	75 mm	1.38 "	65.6 mm	35 mm	1.5 m	59 in	55024 55032 Class B 60950-1 61000-3-2 61000-3-3 62368-1 C22.2 No. 60950-1	Multi-Blade	Multi-Blade (Included)	100 mW	Wall Mount (Class II)	1 A	International	CB Scheme CCC CSA EN IEC PSE RCM UL	24 V	0.349 lb	158.3 g	CoC Tier 2 Level VI	90 VAC	264 VAC	24 W	9.5 mm	5.5 mm
CUI Inc. SMI24-5-V-P5R	40 °C	Positive Center	2.1 mm		Barrel Plug R/A	ITE (Commercial)	2.58 "	2.95 in	75 mm	1.38 "	65.6 mm	35 mm	1 m	39.4 "	55024 55032 Class B 60950-1 61000-3-2 61000-3-3 62368-1 C22.2 No. 60950-1	Multi-Blade	Multi-Blade (Included)	100 mW	Wall Mount (Class II)	4 A	International	CB Scheme CCC CSA EN IEC PSE RCM UL	5 V	0.349 lb	158.3 g	CoC Tier 2 Level VI	90 VAC	264 VAC	20 W	9.5 mm	5.5 mm
CUI Inc. SMI24-48-V-P5	40 °C	Positive Center	9.5 mm	2.1 mm 5.5 mm	Barrel Plug	ITE (Commercial)	2.58 "	2.95 in	75 mm	1.38 "	65.6 mm	35 mm	1.5 m	59 in	55024 55032 Class B 60950-1 61000-3-2 61000-3-3 62368-1 C22.2 No. 60950-1	Multi-Blade	Multi-Blade (Included)	100 mW	Wall Mount (Class II)	500 mA	International	CB Scheme CCC CSA EN IEC PSE RCM UL	48 V	0.349 lb	158.3 g	CoC Tier 2 Level VI	90 VAC	264 VAC	24 W
CUI Inc. SMI24-12-V-P6R	40 °C	Positive Center	9.5 mm	2.5 mm 5.5 mm	Barrel Plug R/A	ITE (Commercial)	2.58 "	2.95 in	75 mm	1.38 "	65.6 mm	35 mm	1.5 m	59 in	55024 55032 Class B 60950-1 61000-3-2 61000-3-3 62368-1 C22.2 No. 60950-1	Multi-Blade	Multi-Blade (Included)	100 mW	Wall Mount (Class II)	2 A	International	CB Scheme CCC CSA EN IEC PSE RCM UL	12 V	0.349 lb	158.3 g	CoC Tier 2 Level VI	90 VAC	264 VAC	24 W

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 14.40
		5	$ 13.83
		10	$ 13.59
		25	$ 13.28
		50	$ 13.05
		100	$ 12.82
		300	$ 12.47
		500	$ 12.31

Description

General part information

SMI24 Series

5V 20 W AC/DC External Wall Mount (Class II) Adapter Multi-Blade (Sold Separately) Input
