Specification	TR9CE3000CLWCIMR6B

Applications	Medical, ITE (Commercial), Household Appliances
Approval Agency	UL, cETLus, IEC, VCCI, EAC, PSE, CE, RCM, ETL, S-Mark, Ukraine, CB, UKCA, WEEE, CCC, LPS
Cord Length	72 in
Current - Output (Max)	3 A
Efficiency	CoC Tier 2, Level V
Form	Desktop (Class I)
Input Connector	IEC 320-C14
Input Type	Cord (Sold Separately)
No Load Power Consumption	75 mW
Operating Temperature (Max)	40 °C
Operating Temperature (Min)	-10 °C
Output Connector	Barrel Plug Locking
Output Connector I.D.	2.1 mm
Output Connector Length	10 mm
Output Connector O.D.	5.5 mm
Polarization	Positive Center
Power (Watts)	36 W
Region Utilized	International
Size / Dimension Height	1.4 in
Size / Dimension Length	4.46 in
Size / Dimension Width	1.97 in
Standard Number	62368-1, 60335-1, 60950-1, 60601-1
Voltage - Input (AC) Maximum	264 V
Voltage - Input (AC) Minimum	90 V
Voltage - Output	12 V

TR9CE3000 Series

Part	Cord Length	Efficiency	Standard Number	Voltage - Input (AC) Minimum	Voltage - Input (AC) Maximum	Form	Region Utilized	Size / Dimension Height	Size / Dimension Length	Size / Dimension Width	Applications	No Load Power Consumption (Max)	Current - Output (Max)	Approval Agency	Polarization	Operating Temperature (Min)	Operating Temperature (Max)	Output Connector Length	Output Connector	Output Connector O.D.	Output Connector I.D.	Voltage - Output	Input Connector	Input Type	Power (Watts)	No Load Power Consumption
GlobTek, Inc. TR9CE3000L9PCIMR6B	47.2 in	CoC Tier 2 Level VI	1310 60335-1 60601-1-11 60601-1-2 60950-1 62368-1	90 V	264 V	Desktop (Class I)	International	1.4 in	4.46 in	1.97 in	Household Appliances ITE (Commercial) Medical	75 mW	3 A	CB CCC CE EAC ETL LPS PSE RCM S-Mark UKRSepro VCCI	Positive Center	-10 °C	40 °C	9.5 mm	Barrel Plug	5.5 mm	2.5 mm	12 V	IEC 320-C14	Cord (Sold Separately)	36 W
GlobTek, Inc. TR9CE3000CLWCIMR6B	72 in	CoC Tier 2 Level V	60335-1 60601-1 60950-1 62368-1	90 V	264 V	Desktop (Class I)	International	1.4 in	4.46 in	1.97 in	Household Appliances ITE (Commercial) Medical		3 A	CB CCC CE cETLus EAC ETL IEC LPS PSE RCM S-Mark UKCA Ukraine UL VCCI WEEE	Positive Center	-10 °C	40 °C	10 mm	Barrel Plug Locking	5.5 mm	2.1 mm	12 V	IEC 320-C14	Cord (Sold Separately)	36 W	75 mW
