IPU95R3K7P7AKMA1

Active

Infineon Technologies

MOSFET, 950V, 2A, 150DEG C, 22W

Search across all available documentation for this part.

Active

Infineon Technologies

MOSFET, 950V, 2A, 150DEG C, 22W

Technical Specifications

Parameters and characteristics for this part

Specification	IPU95R3K7P7AKMA1

Current - Continuous Drain (Id) @ 25°C	2 A
Drain to Source Voltage (Vdss)	950 V
Drive Voltage (Max Rds On, Min Rds On)	10 V
FET Type	N-Channel
Gate Charge (Qg) (Max) @ Vgs	6 nC
Mounting Type	Through Hole
Operating Temperature [Max]	150 °C
Operating Temperature [Min]	-55 °C
Package / Case	IPAK, TO-251-3 Short Leads, TO-251AA
Power Dissipation (Max) [Max]	22 W
Rds On (Max) @ Id, Vgs	3.7 Ohm
Supplier Device Package	PG-TO251-3
Technology	MOSFET (Metal Oxide)
Vgs (Max)	20 V
Vgs(th) (Max) @ Id	3.5 V

Part	Technology	Power Dissipation (Max) [Max]	Rds On (Max) @ Id, Vgs	Mounting Type	Package / Case	Supplier Device Package	Operating Temperature [Min]	Operating Temperature [Max]	Current - Continuous Drain (Id) @ 25°C	Vgs(th) (Max) @ Id	Gate Charge (Qg) (Max) @ Vgs	FET Type	Vgs (Max)	Drive Voltage (Max Rds On, Min Rds On)	Drain to Source Voltage (Vdss)
Infineon Technologies IPU95R3K7P7AKMA1	MOSFET (Metal Oxide)	22 W	3.7 Ohm	Through Hole	IPAK TO-251-3 Short Leads TO-251AA	PG-TO251-3	-55 °C	150 °C	2 A	3.5 V	6 nC	N-Channel	20 V	10 V	950 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

N-Channel 950 V 2A (Tc) 22W (Tc) Through Hole PG-TO251-3
