SY100S301FC
ActiveMicrochip Technology
IC NOR/OR GATE 3-CIR 24-CERPACK
Deep-Dive with AI
Search across all available documentation for this part.
SY100S301FC
ActiveMicrochip Technology
IC NOR/OR GATE 3-CIR 24-CERPACK
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | SY100S301FC |
|---|---|
| Logic Type | NOR/OR Gate |
| Mounting Type | Surface Mount |
| Number of Circuits | 3 |
| Number of Inputs | 15 |
| Number of Inputs [custom] | 5 |
| Number of Inputs [custom] | 5 |
| Number of Inputs [custom] | 5 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | 0 °C |
| Output Type | Differential |
| Package / Case | CerPack, 24-CQFlatPack |
| Schmitt Trigger Input | False |
| Supplier Device Package | 24-CerPack |
| Voltage - Supply [Max] | 5.5 V |
| Voltage - Supply [Min] | 4.2 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 57 | $ 5.35 | |
100S301 Series
IC NOR/OR GATE 3-CIR 24-CERPACK
| Part | Number of Inputs [custom] | Number of Inputs [custom] | Number of Inputs [custom] | Number of Inputs | Logic Type | Schmitt Trigger Input | Package / Case | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Number of Circuits | Output Type | Voltage - Supply [Max] | Voltage - Supply [Min] | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Microchip Technology SY100S301FC | 5 | 5 | 5 | 15 | NOR/OR Gate | 24-CQFlatPack, CerPack | Surface Mount | 0 °C | 85 °C | 3 | Differential | 5.5 V | 4.2 V | 24-CerPack |
Description
General part information
100S301 Series
NOR/OR Gate Configurable 3 Circuit 15 Input (5, 5, 5) Input 24-CerPack
Documents
Technical documentation and resources
No documents available
