TMS-108-55-G-S

Active

Samtec Inc.

.050" (1.27MM) MICRO HEADER

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsThrough-hole Micro Header, 0.050" x 0.100" Pitch TMS Datasheet +1

TMS-108-55-G-S

Active

Samtec Inc.

.050" (1.27MM) MICRO HEADER

Deep-Dive with AI

DocumentsThrough-hole Micro Header, 0.050" x 0.100" Pitch TMS Datasheet +1

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	TMS-108-55-G-S

null

TMS-108 Series

Part	Insulation Color	Contact Finish - Mating	Overall Contact Length	Overall Contact Length	Contact Shape	Insulation Material	Insulation Height	Insulation Height	Contact Material	Contact Type	Mounting Type	Material Flammability Rating	Termination	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Length - Mating	Contact Length - Mating	Shrouding	Contact Length - Post [x]	Contact Length - Post [x]	Connector Type	Pitch - Mating	Pitch - Mating	Number of Positions	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Number of Positions Loaded	Contact Finish - Post	Current Rating (Amps)	Operating Temperature [Min]	Operating Temperature [Max]	Fastening Type	Number of Rows	Number of Positions	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Insulation Height [z]	Insulation Height [z]
Samtec Inc. TMS-108-55-G-S
Samtec Inc. TMS-108-51-G-S	Black	Gold	0.41 in	10.41 mm	Square	Liquid Crystal Polymer (LCP)	0.1 in	2.54 mm	Phosphor Bronze	Male Pin	Through Hole	UL94 V-0	Solder	10 çin	0.25 çm	0.19 "	4.83 mm	Unshrouded	0.12 in	3.05 mm	Header	0.05 in	1.27 mm	8	3 µin	0.076 µm	All	Gold	5 A	-55 °C	125 °C	Push-Pull	1
Samtec Inc. TMS-108-51-T-D	Black		0.41 in	10.41 mm	Square	Liquid Crystal Polymer (LCP)	0.1 in	2.54 mm	Phosphor Bronze	Male Pin	Through Hole	UL94 V-0	Solder			0.19 "	4.83 mm	Unshrouded	0.12 in	3.05 mm	Header	0.05 in	1.27 mm				All	Tin	5 A	-55 °C	105 ░C	Push-Pull	2	16	2.54 mm	0.1 in
Samtec Inc. TMS-108-02-S-D	Black	Gold			Square	Liquid Crystal Polymer (LCP)	0.1 in	2.54 mm	Phosphor Bronze	Male Pin	Through Hole	UL94 V-0	Solder	30 Áin	0.76 Ám	0.1 in	2.54 mm	Unshrouded	0.12 in	3.05 mm	Header	0.05 in	1.27 mm				All	Tin	5 A	-55 °C	125 °C	Push-Pull	2	16	2.54 mm	0.1 in
Samtec Inc. TMS-108-51-T-S	Black		0.41 in	10.41 mm	Square	Liquid Crystal Polymer (LCP)	0.1 in	2.54 mm	Phosphor Bronze	Male Pin	Through Hole	UL94 V-0	Solder			0.19 "	4.83 mm	Unshrouded	0.12 in	3.05 mm	Header	0.05 in	1.27 mm	8			All	Tin	5 A	-55 °C	105 ░C	Push-Pull	1
Samtec Inc. TMS-108-02-G-S-RA	Black	Gold			Square	Liquid Crystal Polymer (LCP)			Phosphor Bronze	Male Pin	Through Hole Right Angle	UL94 V-0	Solder	10 çin	0.25 çm	0.1 in	2.54 mm	Unshrouded	0.14 in	3.56 mm	Header	0.05 in	1.27 mm	8	3 µin	0.076 µm	All	Gold	5 A	-55 °C	125 °C	Push-Pull	1				0.098 in	2.5 mm
Samtec Inc. TMS-108-60-L-D	Black	Gold	0.825 in	20.95 mm	Square	Liquid Crystal Polymer (LCP)	0.1 in	2.54 mm	Phosphor Bronze	Male Pin	Through Hole	UL94 V-0	Solder	10 çin	0.25 çm	0.605 in	15.37 mm	Unshrouded	0.12 in	3.05 mm	Header	0.05 in	1.27 mm				All	Tin	5 A	-55 °C	125 °C	Push-Pull	2	16	2.54 mm	0.1 in
Samtec Inc. TMS-108-51-S-S	Black	Gold	0.41 in	10.41 mm	Square	Liquid Crystal Polymer (LCP)	0.1 in	2.54 mm	Phosphor Bronze	Male Pin	Through Hole	UL94 V-0	Solder	30 Áin	0.76 Ám	0.19 "	4.83 mm	Unshrouded	0.12 in	3.05 mm	Header	0.05 in	1.27 mm	8			All	Tin	5 A	-55 °C	125 °C	Push-Pull	1
Samtec Inc. TMS-108-02-S-S	Black	Gold			Square	Liquid Crystal Polymer (LCP)	0.1 in	2.54 mm	Phosphor Bronze	Male Pin	Through Hole	UL94 V-0	Solder	30 Áin	0.76 Ám	0.1 in	2.54 mm	Unshrouded	0.12 in	3.05 mm	Header	0.05 in	1.27 mm	8			All	Tin	5 A	-55 °C	125 °C	Push-Pull	1
Samtec Inc. TMS-108-02-SM-S	Black	Gold			Square	Liquid Crystal Polymer (LCP)	0.1 in	2.54 mm	Phosphor Bronze	Male Pin	Through Hole	UL94 V-0	Solder	30 Áin	0.76 Ám	0.1 in	2.54 mm	Unshrouded	0.12 in	3.05 mm	Header	0.05 in	1.27 mm	8			All	Tin	5 A	-55 °C	125 °C	Push-Pull	1

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	1	$ 2.10

Description

General part information

TMS-108 Series

Connector Header position

Documents

Technical documentation and resources

Through-hole Micro Header, 0.050" x 0.100" Pitch

TMS Datasheet

Datasheet
