ASB01703HA3-00CAH

Active

Delta Electronics

FAN BLOWER 17X3MM 3VDC RECT CONN

Search across all available documentation for this part.

Active

Delta Electronics

FAN BLOWER 17X3MM 3VDC RECT CONN

Technical Specifications

Parameters and characteristics for this part

Specification	ASB01703HA3-00CAH

Air Flow	0.51 CFM
Air Flow	0.014 m³/min
Bearing Type	Sleeve
Current Rating (Amps)	60 mA
Fan Type	Blower
Features	Speed Sensor (Tach), Locked Rotor Protection
Lifetime @ Temp.	30000 Hrs
Material - Blade	Plastic
Material - Frame	Plastic
Noise	30 dB(A)
Operating Temperature [Max]	60 °C
Operating Temperature [Max]	60 °C
Operating Temperature [Min]	-10 °C
Operating Temperature [Min]	-10 °C
Power (Watts)	180 mW
RPM	12000 RPM
Size / Dimension [x]	17 mm
Size / Dimension [y]	17 mm
Static Pressure	0.071 in H2O
Static Pressure	17.6 Pa
Termination	3 Position Rectangular Connector
Voltage - Rated	3 VDC
Voltage Range [Max]	3.5 VDC
Voltage Range [Min]	2 V
Weight	1.81 g
Weight	0.004 lb
Width [y]	3 mm

Part	Material - Frame	Voltage - Rated	Termination	RPM	Power (Watts)	Voltage Range [Min]	Voltage Range [Max]	Size / Dimension [y]	Size / Dimension [x]	Width [y]	Weight	Weight	Bearing Type	Air Flow	Air Flow	Current Rating (Amps)	Fan Type	Static Pressure	Static Pressure	Operating Temperature [Min]	Operating Temperature [Min]	Operating Temperature [Max]	Operating Temperature [Max]	Features	Material - Blade	Noise	Lifetime @ Temp.
Delta Electronics ASB01703HA3-00CAH	Plastic	3 VDC	3 Position Rectangular Connector	12000 RPM	180 mW	2 V	3.5 VDC	17 mm	17 mm	3 mm	1.81 g	0.004 lb	Sleeve	0.51 CFM	0.014 m³/min	60 mA	Blower	0.071 in H2O	17.6 Pa	-10 °C	-10 °C	60 °C	60 °C	Locked Rotor Protection Speed Sensor (Tach)	Plastic	30 dB(A)	30000 Hrs

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Fan Blower 3VDC Square - 17mm L x 17mm H Sleeve 0.510 CFM (0.014m³/min) 3 Position Rectangular Connector
