PD10AB57

Active

TE Connectivity Aerospace, Defense and Marine

RELAY GEN PURPOSE SPST 10A 24V

Search across all available documentation for this part.

Active

TE Connectivity Aerospace, Defense and Marine

RELAY GEN PURPOSE SPST 10A 24V

Technical Specifications

Parameters and characteristics for this part

RELAY GEN PURPOSE SPST 10A 24V

Part	Operate Time	Coil Resistance	Seal Rating	Coil Voltage	Contact Rating (Current)	Coil Current	Operating Temperature [Max]	Operating Temperature [Min]	Load - Max Switching	Must Operate Voltage	Termination Style	Must Release Voltage	Release Time	Contact Form	Relay Type	Mounting Type	Coil Type	Switching Voltage
TE Connectivity Aerospace, Defense and Marine PD10AB57	10 ms	290 Ohms	Sealed - Vacuum	24 VDC	10 A	82.8 mA	85 °C	-40 °C	3200 VA	16 VDC	Screw Terminal	1 VDC	10 ms	SPST-NO (1 Form A)	General Purpose	Chassis Mount	Non Latching	320 VDC

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

General Purpose Relay SPST-NO (1 Form A) 24VDC Coil Chassis Mount
