APS25A77128G-3BTM

Apacer Memory America

SSD 128GB 2.5" MLC SATA III 5V

Search across all available documentation for this part.

Apacer Memory America

SSD 128GB 2.5" MLC SATA III 5V

Technical Specifications

Parameters and characteristics for this part

Specification	APS25A77128G-3BTM

Current - Max [Max]	470 mA
Form Factor	2.5 in
Memory Size	128 GB
Memory Type	Solid State Drive (SSD) FLASH - NAND (MLC)
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	0 °C
Size / Dimension [x]	100 mm
Size / Dimension [y]	69.85 mm
Size / Dimension [z]	6.9 mm
Speed - Read	520 MB/s
Speed - Write	300 MB/s
Type	SATA III

Part	Memory Type	Current - Max [Max]	Speed - Write	Type	Form Factor	Speed - Read	Memory Size	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Operating Temperature [Max]	Operating Temperature [Min]
Apacer Memory America APS25A77128G-3BTM	Solid State Drive (SSD) FLASH - NAND (MLC)	470 mA	300 MB/s	SATA III	2.5 in	520 MB/s	128 GB	69.85 mm	6.9 mm	100 mm	70 °C	0 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 172.65

General part information

Solid State Drive (SSD) FLASH - NAND (MLC) 128GB SATA III 2.5" 5V
