Specification	5151-0.5-5

Adhesive	Silicone Thermosetting
Backing, Carrier	Polytetrafluoroethylene, PTFE
Color	Brown
Length (ft)	15 ft
Length (yd)	5 yd
Shelf Life	24 Months
Shelf Life Start	Date of Manufacture
Storage/Refrigeration Temperature (Maximum)	80 °F
Storage/Refrigeration Temperature (Minimum)	60 °F
Tape Type	Glass Cloth
Temperature Range (Max)	400 °F
Temperature Range (Min)	-100 °F
Thickness	0.0053 in
Thickness - Adhesive	0.0023 in
Thickness - Backing, Carrier	0.003 in
Usage	General Purpose
Width	12.7 mm

5151 Series

Part	Shelf Life Start	Shelf Life	Storage/Refrigeration Temperature (Maximum)	Storage/Refrigeration Temperature (Minimum)	Backing, Carrier	Length (yd)	Length (ft)	Adhesive	Color	Thickness	Thickness - Backing, Carrier	Temperature Range (Min)	Temperature Range (Max)	Tape Type	Width	Thickness - Adhesive	Usage
3M (TC) 3M 5151 0.625" X 36YD	Date of Manufacture	24 Months	80 °F	60 °F	Polytetrafluoroethylene PTFE	36 yd	108 ft	Silicone Thermosetting	Brown	0.0053 in	0.003 in	-100 °F	500 °F	Glass Cloth	0.63 in	0.0023 in
3M (TC) 3M 5151 2.83" X 36YD	Date of Manufacture	24 Months	80 °F	60 °F	Polytetrafluoroethylene PTFE	36 yd	108 ft	Silicone Thermosetting	Brown	0.0053 in	0.003 in	-100 °F	500 °F	Glass Cloth	2.83 in	0.0023 in
3M (TC) 5151-9-5	Date of Manufacture	24 Months	80 °F	60 °F	Polytetrafluoroethylene PTFE	5 yd	15 ft	Silicone Thermosetting	Brown	0.0053 in	0.003 in	-100 °F	400 °F	Glass Cloth	9 in	0.0023 in	General Purpose
3M (TC) 3M 5151 8" X 36YD	Date of Manufacture	24 Months	80 °F	60 °F	Polytetrafluoroethylene PTFE	36 yd	108 ft	Silicone Thermosetting	Brown	0.0053 in	0.003 in	-100 °F	500 °F	Glass Cloth	8 in	0.0023 in
3M (TC) 3M 5151 2.75" X 36YD	Date of Manufacture	24 Months	80 °F	60 °F	Polytetrafluoroethylene PTFE	36 yd	108 ft	Silicone Thermosetting	Brown	0.0053 in	0.003 in	-100 °F	500 °F	Glass Cloth	2.75 in	0.0023 in
3M (TC) 3M 5151 0.25" X 36YD	Date of Manufacture	24 Months	80 °F	60 °F	Polytetrafluoroethylene PTFE	36 yd	108 ft	Silicone Thermosetting	Brown	0.0053 in	0.003 in	-100 °F	500 °F	Glass Cloth	0.25 in	0.0023 in
3M (TC) 3M 5151 5" X 36YD	Date of Manufacture	24 Months	80 °F	60 °F	Polytetrafluoroethylene PTFE	36 yd	108 ft	Silicone Thermosetting	Brown	0.0053 in	0.003 in	-100 °F	500 °F	Glass Cloth	5 in	0.0023 in
3M (TC) 5151-3-5	Date of Manufacture	24 Months	80 °F	60 °F	Polytetrafluoroethylene PTFE	5 yd	15 ft	Silicone Thermosetting	Brown	0.0053 in	0.003 in	-100 °F	400 °F	Glass Cloth	3 in	0.0023 in	General Purpose
3M (TC) 3M 5151 1.875" X 36YD	Date of Manufacture	24 Months	80 °F	60 °F	Polytetrafluoroethylene PTFE	36 yd	108 ft	Silicone Thermosetting	Brown	0.0053 in	0.003 in	-100 °F	500 °F	Glass Cloth	1.88 in	0.0023 in
3M (TC) 7-5-5151	Date of Manufacture	24 Months	80 °F	60 °F	Polytetrafluoroethylene PTFE	5 yd	15 ft	Silicone Thermosetting	Brown	0.0053 in	0.003 in	-100 °F	400 °F	Glass Cloth	7 in	0.0023 in	General Purpose
