CCF1.50TB50

Active

Techflex

EXPAND SLEEVE 1.5"X50' BLK/WHT

Search across all available documentation for this part.

Active

Techflex

EXPAND SLEEVE 1.5"X50' BLK/WHT

Technical Specifications

Parameters and characteristics for this part

Specification	CCF1.50TB50

Abrasion Protection	Abrasion and Cut Resistant, Fray Resistant
Color	White, Black
Diameter - Inside, Expanded [diameter]	2 in
Diameter - Inside, Expanded [diameter]	50.8 mm
Diameter - Inside, Non-Expanded [diameter]	1.5 in
Diameter - Inside, Non-Expanded [diameter]	38.1 mm
Features	Clean Cut, Self Extinguishing
Heat Protection	Flame Retardant
Length	15.24 m
Length [x]	50 ft
Material	Polyethylene Terephthalate (PET), Halogen Free
Material Flammability Rating	UL VW-1
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-70 °C
Type	Sleeve
Type Attributes	Expandable
Wall Thickness	0.024 in
Wall Thickness	0.61 mm

EXPAND SLEEVE 1.5"X50' BLK/WHT

Part	Diameter - Inside, Expanded [diameter]	Diameter - Inside, Expanded [diameter]	Wall Thickness	Wall Thickness	Material	Type	Abrasion Protection	Diameter - Inside, Non-Expanded [diameter]	Diameter - Inside, Non-Expanded [diameter]	Color	Length	Length [x]	Operating Temperature [Max]	Operating Temperature [Min]	Heat Protection	Material Flammability Rating	Features	Type Attributes
Techflex CCF1.50TB50	2 in	50.8 mm	0.024 in	0.61 mm	Polyethylene Terephthalate (PET), Halogen Free	Sleeve	Abrasion and Cut Resistant, Fray Resistant	1.5 in	38.1 mm	Black, White	15.24 m	50 ft	125 °C	-70 °C	Flame Retardant	UL VW-1	Clean Cut, Self Extinguishing	Expandable

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Sleeve X 50.00' (15.24m) Black, White
